Connection Status - PPPoE

If using PPPoE (PPP over Ethernet), a screen like the following example will
be displayed when the "Connection Details" button is clicked.
Data - PPPoE Screen
Connection
Physical Address
IP Address
Network Mask
PPPoE Link
Status
Connection Log
Connection Log
Buttons
Connect
Disconnect
Clear Log
Refresh
The hardware address of this device, as seen by remote devices
on the Internet. (This is different to the hardware address seen
by devices on the local LAN.)
The IP Address of this device, as seen by Internet users. This
address is allocated by your ISP (Internet Service Provider).
The Network Mask associated with the IP Address above.
This indicates whether or not the connection is currently estab-
lished.
• If the connection does not exist, the "Connect" button can be
used to establish a connection.
• If the connection currently exists, the "Disconnect" button
can be used to break the connection.
• The Connection Log shows status messages relating to the
existing connection.
• The most common messages are listed in the table below.
• The "Clear Log" button will restart the Log, while the Refresh
button will update the messages shown on screen.
If not connected, establish a connection to your ISP.
If connected to your ISP, hang up the connection.
Delete all data currently in the Log. This will make it easier to
read new messages.
Update the data on screen.
DC-202 xDSL/Cable Broadband router
36
