Defining Your Own Virtual Servers - Sitecom DC-202 Full Manual

Buttons
Defaults
Disable All
Update Se-
lected Server
Add as new
Server
Delete
Clear Form

Defining your own Virtual Servers

If the type of Server you wish to use is not listed on the Virtual Servers
screen, you can define and manage your own Servers:
Create a new
Server:
Modify (Edit) a
Server:
Delete a Server:
From the Internet, ALL Virtual Servers
have the IP Address allocated by your
ISP.
This will delete any Servers you have defined, and set the pre-
defined Servers to use their default port numbers.
This will cause the "Enable" setting of all Virtual Servers to be set
OFF.
Update the current Virtual Server entry, using the data shown in
the "Properties" area on screen.
Add a new entry to the Virtual Server list, using the data shown in
the "Properties" area on screen. The entry selected in the list is
ignored, and has no effect.
Delete the current Virtual Server entry. Note that the pre-defined
Servers can not be deleted. Only Servers you have defined yourself
can be deleted.
Clear all data from the "Properties" area, ready for input of a new
Virtual Server entry.
For each entry, the PC must be run-
ning the appropriate Server
software.
1. Click "Clear Form"
2. Enter the required data, as described above.
3. Click "Add".
4. The new Server will now appear in the list.
1. Select the desired Server from the list
2. Make any desired changes (for example, change the
Enable/Disable setting).
3. Click "Update" to save changes to the selected Server.
1. Select the entry from the list.
2. Click "Delete".
Note: You can only delete Servers you have defined. Pre-
defined Server cannot be deleted.
DC-202 xDSL/Cable Broadband router
56
