For additional information about
Irrigation set-up, refer to the Hall
Irrigation Instruction Manual. If
the Instruction Manual can not be
located, contact Hall Surgical for
information concerning
issues. Replacement Instruction
Manuals are available.
See Handpiece Mode Selection
instructions for setting irrigation
flow rates (page 38).

CONTROLLER STAND

To attach the MicroChoice™ Controller to the stand:
1. For assembly of the Controller stand, follow the directions included
with the stand.
2. Match the opening on the underside of the Controller with the top plate
on the stand and push the two together.
3. Position the Controller in the center of the stand by pulling down the
single metal, spring-loaded screw located in the center of the stand.
4. Ensure the two (2) plastic screws are centered with the openings on the
bottom of the Controller. Tighten the screws securely to attach the
Controller to the stand.
®
these
