MICROCHOICE FOOTSWITCH CONTROL
™
Warning: Place the Safe Slide in the "safe" position when not in use.
Warning: To avoid unintentional activation, unplug the Footswitch
when using a levered handpiece. When the Footswitch is attached to the
Controller it will remain active.
Caution: The mode of activation initiated first, Activation Lever or
Footswitch, has operational control of the handpiece even if the other is
inadvertently depressed simultaneously. The second activation mode
will not control the handpiece until both activation methods are
released.
Caution: The Medium Speed Drill and High Speed Drill will operate
in reverse if the left (Reverse) pedal is depressed.
®
Note: Micro E Handpieces will not operate with the MicroChoice
Footswitch.
1. Align the red indicator dots
and plug the Footswitch Cord
connection into the Footswitch
receptacle on the front of the
Controller.
2. To activate the handpiece,
move the Safe/Run Slide to the
"run" position, then depress
the Footswitch.
