Follow-up Procedure
Pack the removed component, and return it to Huawei local warehouse.

4.4.5 Replacing an AC SPD Module

Prerequisites


Do not replace an AC SPD module during a thunderstorm.
Procedure
Step 1 Connect the ground cable to the ESD wrist strap and wear the ESD wrist strap and ESD
gloves.
Step 2 Hold down the faulty AC SPD module and pull it out, as shown in
Step 3 Install a new AC SPD module, as shown in
Figure 4-10 Replacing an AC SPD module
Step 4 Disconnect the ground cable from the ESD wrist strap and take off the ESD wrist strap and
ESD gloves.
----End
Follow-up Procedure
Check that the alarm for the AC SPD is cleared.
Issue 03 (2020-01-04)
You have obtained an ESD wrist strap or a pair of ESD gloves, an ESD box or bag, and
the cabinet door key.
The new AC SPD module is intact and the indication window is green.
Copyright © Huawei Technologies Co., Ltd.
Figure
Figure 4-10.
4 Maintenance
4-10.
