TP48120A-HD15A1, TP48120A-HD15A2,
TP48200A-HD15A1, and TP48200A-HD15A2 Telecom
Power
User Manual
(7) Ground bar
(10) Space for
installing batteries
(13) Battery circuit
breakers
(16) RTN+ busbar
(19) Heater
Issue 03 (2020-01-04)
(8) Space for installing
customer equipment
(11) Battery low voltage
disconnection (BLVD) circuit
breakers
(14) SMU06C
(17) Heat exchanger core
