4. OVERVIEW

4.1. SWITCHES AND INTERFACES

4.1-1
UPS 10 to 40 kVA
Options slot 1
Ethernet network
USB connector
Serial connector RS232/485
Serial connector RS232
Options slot 2
Q1, Q2 switches
Switch in position 0
Q6 switch
Switch in position 0 (OFF)
klick to
klick to
www www
u-s-v
Y O U R C O N N E C T I O N TO S A F E T Y
ACDC-DCDC
AUX
MAINS
Q2
MAINS
Q1
B
Switch in position 1 (UPS)
CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00
