Fametech TP-1115-RK3399 Quick Installation Manual


Specifications
Model Name
Rockchip RK3399, Dual-core Cortex A72 up to 1.8GHz + Quad-core Cortex
Core Logic
System Memory
Storage
LCD Panel
Touch Panel
Speaker
Wi-Fi
I/O Expansion
3 x USB-A 3.0 and 1 x USB-C 3.0 (Bottom)
USB
LAN
COM
HDMI
Audio
Cash Drawer 1 x RJ11 port supports 1 cash drawer with 12V or 24V
DC Power Out
DC Power In
Power Management
Power Adapter
Mechanical & Environmental
Dust and Water
Tilt Adjustment
355 (W) x 303 (H) x 205 (D)mm (w/ Standard Base)
Dimension
355 (W) x 312 (H) x 200 (D)mm (w/ Folding Base)
Weight
Certification
Operation System
Operation Condition 0°C to +40°C / 20 to 80% without condensation
Storage Condition -20°C to +55°C / 20 to 85% without condensation
Optional Accessories
2nd Display
Customer Display
MSR Comply with ISO 7811 and Three Track support
MSR - Comply with ISO 7811/JISII and Three Track
Combo Card Reader
RFID - Comply Mifare, ISO14443AB-4 and Felica
i-Button
4G LTE 4G LTE Mini-PCIe with External Antenna Rod
VESA Bracket
*The product information and specifications are subject to change without prior notice
TP-1115-RK3399
A53 up to 1.4GHz
Onboard 4GB LPDDR4 1866MHz
Onboard 32GB eMMC 5.1 (Max. 64GB)
1 x Micro SD Card Slot (up to 128GB)
15-inch TFT LCD with LED Backlight
1024 (W) RGB x 768 (H)
True-Flat Projected Capacitive Multi Touch
1 x 2W High Quality Speaker
Wi-Fi IEEE 802.11 a/b/g/n/ac
2 x USB 2.0 (Panel Side)
1 x RJ45 10/100/1000Mbps Giga Ethernet
2 x COM (RJ45), w/ RI/5V/12V by jump
1 x HDMI Port
1 x Line-out and 1 x MIC-in
1 x +12V Power Out
1 x Standard Mini-DIN 4PIN type
12V@5.0A, 60W Adapter
IP65 on Front Panel
15° ~ 85 ° (w/ Standard Base)
0° ~ 90 ° (w/ Folding Base)
4.3 kg
CE/FCC/LVD
Android 9.0*
10.1" (1280 x 800) LCD Display
Option : PCAP Touch Panel
VFD and LCD Customer Display
Dallas i-button Reader
VESA-Compatible, 75 x 75 (mm)
Fanless Full-Flat POS Terminal
IMPORTANT SAFETY INFORMATION
 Read following instructions carefully.

Use only parts, especially power adapter, recommended by the manufacturer;
unapproved parts may be hazardous.

Make sure that the voltage applied to the power outlet is within the specified range
(100VAC ~240VAC).
Improper power source voltage range will cause damage.
 Power off the system and remove the power adapter while cleaning the system.
 Before powering on the system, make sure all the peripherals are
firmly installed.
.
TP-1115-RK3399
Quick Installation Guide
