Fametech TP-9116 Quick Installation Manual


Specifications
Model Name
Rockchip RK3399, Dual-core Cortex A72 up to 1.8GHz + Quad-core
Processor
System Memory
Storage
LCD Panel - I 15.6-inch TFT LCD, 1920 (W) RGB x 1080 (H)
LCD Panel - II 15.6-inch TFT LCD, 1366 (W) RGB x 768 (H)
Touch Panel True-Flat Projected Capacitive Multi Touch
Speaker
Wi-Fi
I/O Interface
USB
LAN 1 x RJ45 10/100/1000Mbps Giga Ethernet
COM 2 x COM (RJ45), w/ NC/5V/12V by jump
HDMI
Audio
Cash Drawer 1 x RJ11 port supports 2 cash drawer, w/ 12V/24V by jumper
DC Power Out
DC Power In
Power Management
Power Adapter
Mechanical & Environmental
Dust and Water
Tilt Adjustment
Dimension
Weight
Certification
Operation System
0°C to +40°C / 20 to 80% without condensation
Operation Condition
-20°C to +55°C / 20 to 85% without condensation
Storage Condition
Optional Accessories
2nd Display
Customer Display
Bi-directional, Comply with ISO 7811 and Three Track support
MSR
4G LTE 4G LTE Mini-PCIe with External Antenna Rod
*The product information and specifications are subject to change without prior notice.
TP-9116
Cortex A53 up to 1.4GHz
Onboard 4GB LPDDR4 1866MHz
Onboard 32GB eMMC 5.1 (Max. 64GB)
1 x Micro SD Card Slot (up to 128GB)
1 x 2W High Quality Speaker
Wi-Fi IEEE 802.11 a/b/g/n/ac
3 x USB 3.0 Type A
1 x USB-C 3.0 Type C (w/ADB)
1 x USB 2.0 Type A
1 x HDMI Port
1 x Line-out and 1 x MIC-in
1 x DC 12V Power Out (DC 2.1mm)
1 x Standard DIN 4PIN type
12V@5A, 60W Adapter
IP65 on Front Bezel
0° ~ 90°
389 (W) x 352 (H) x 210 (D)mm
4.3 kg
CE/FCC/LVD
Android 9.0*
10.1" (1280 x 800) LCD Display
Optional PCAP Touchscreen
VFD and LCD Customer Display
TP-9116
15.6-inch Touch Screen POS Terminal
Quick Installation Guide
IMPORTANT SAFETY INFORMATION
 Read following instructions carefully.
 Use only parts, especially power adapter, recommended by the manufacturer;
unapproved parts may be hazardous.
 Make sure that the voltage applied to the power outlet is within the specified
range (100VAC ~240VAC).
Improper power source voltage range will cause damage.
 Power off the system and remove the power adapter while cleaning the system.
 Before powering on the system, make sure all the peripherals are firmly installed.
