The inside of the panel will vary, depending on whether it is a
Q4 or Q5 based controller. The following pictorial shows both
versions:
Rear of Display
Q5 Controller
Interface Board
QUANTUM
LX CONDENSER/VESSEL CONTROL PANEL
™
Communications
Q4 Controller
Quantum™ LX
Controller
MAINTENANCE
Terminal Block
Q4 Panel
Communications
Terminals
Q5 Panel
Power Supply
120 VAC Power
Connection
Power Supply
090.560-M (MAY 2016)
Page 7
120 VAC Power
Connection
