090.560-M (MAY 2016)
Page 6
The following pictorial shows the front of the Control Panel
portion of the unit, and will appear the same for both a Q4 or
Q5 control, and includes the following components:
•
Enclosure
Display
Keypad
QUANTUM
LX CONDENSER/VESSEL CONTROL PANEL
™
MAINTENANCE
QUANTUM™ LX CONDENSER/VESSEL CONTROL PANEL
Front of Enclosure
•
Display
•
Keypad
•
Control Power Switch
Enclosure
Control Power
Switch
