LPK-OH - LEGACY/PHOENIX NG to PROPANE
Gas Conversion Kit
Models:
LEGACY42-IFT
PHOENIX42-IFT
WARNING:
This conversion kit shall be installed by a qualified service
agency in accordance with the manufacturer's instructions
and all applicable code and requirements of the authority
having jurisdiction. If the information in these instructions
is not followed exactly, a fire, explosion or production of
carbon monoxide may result causing property damage,
personal injury or loss of life. The qualified service agency
is responsible for the proper installation of this kit. The
installation is not proper and complete until the operation
of the converted appliance is checked as specified in the
manufacturer's instructions supplied with the kit.
1
Components
LPK-OH
Description
Dexen Valve Regulator Replacement Kit. Includes gas
regulator, conversion label and instructions
Main Burner Orifice (Propane)
Pilot orifice (.014 for Propane)
Installation instructions
Installer conversion label
Table 1.1
Note: The LPK-OH kit is for a one time conversion only.
Discard unused parts.
Note: For gas models not listed, refer to the model's installation instructions for proper conversion kit or contact your Hearth
& Home Technologies dealer. For the dealer nearest you, please visit www.heatilator.com.
Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during installa-
tion. Sheet metal edges are sharp.
Note: An arrow () found in the text signifies change in
content.
Installation
Instructions
1
Advertisement
Related Manuals for Hearth & Home LEGACY42-IFT
Summary of Contents for Hearth & Home LEGACY42-IFT
- Page 1 Installation Instructions LPK-OH - LEGACY/PHOENIX NG to PROPANE Gas Conversion Kit Models: LEGACY42-IFT PHOENIX42-IFT CAUTION! Risk of Cuts, Abrasions or Flying Debris. WARNING: Wear protective gloves and safety glasses during installa- tion. Sheet metal edges are sharp. This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions...
- Page 2 Orifice Sizes for Conversions A. Conversion - Orifices LPK-OH (CONVERT TO PROPANE) Threaded Model Orifice Size .098 LEGACY42-IFT PHOENIX42-IFT Table 2.1 Preparation Required Tools 7/16 in. Open End Wrench (2) 3/4 in. Open End Wrench Safety Glasses Manometer #20 Tamper Proof Torx...
- Page 3 • Remove (2) Side Hearth Refractory pieces. See • Disconnect incoming flexible gas line from gas valve. Figure 3.3. • Remove orange and green wires from the valve. • Slide Burner Assembly towards the front of the appliance and stand upright. Make certain Burner Assembly is stable and will not fall over.
- Page 4 Converting the Appliance The LEGACY42-IFT/PHOENIX42-IFT come equipped with a Dexen PIP valve.(Figure 4.1) use only the Dexen Valve Regulator Replacement Kit or Replacement Valve. Follow the regulator replacement instructions that came with the regulator replacement kit. After completion of the regulator replacement instructions, return to these in- structions.
- Page 5 Replace the Pilot and Burner Orifice WARNING Fire Risk PILOT HOOD • Orifices must be replaced Note: Appearance of pilot may vary. Failure to replace the orifices could result in overheating the gas appliance and possibly damaging your appliance and your home. PILOT ORIFICE A.
- Page 6 B. Replace Burner Orifice(s) Note: Test fittings for leaks with the pilot lit and the burner off. Burner Orifices - Novus NDV & NBV • Using (2) 3/4 in. wrenches, disconnect flexible gas line from threaded orifice. See Figure 5.3. •...
-
Page 7: Adjust The Air Shutter
Adjust the Air Shutter • The LEGACY IFT/PHOENIX42-IFT require the air shutter be removed when the appliance is converted to burn propane. No futher air shutter adjustments need to be made. Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18... - Page 8 Checking Your Conversion A. Leak Test Inlet Gas Pressure Verify the inlet gas supply pressure by connecting a ma- nometer to the inlet side of the valve. If the inlet gas pres- WARNING sure is incorrect, do not adjust without specific approv- al and instruction from the gas supplier.
-
Page 9: Attaching Labels
Attaching Labels All labels must be filled out and/or installed by the individual completing the conversion. This must be finished or the con- Place version is not complete. See Figures 8.1-8.3. conversion • Fill out the installer conversion label (Figure 8.1). After filling label here out the label, clean an area near the existing rating label and attach.
