Hearth & Home LOGS-550BE-B Log Placement Instructions

Log Set Assembly: LOGS-550BE-B
Models: SL-550BE-B, SL-550BE-IPI-B, DV3732SBI
CAUTION: Logs are fragile.
TAB A TAB A
TAB C TAB C
Locating Screw
Figure 1. Log Locating Features Figure 1. Log Locating Features
Use the log locating features in Figure 1 to properly posi-
tion the logs.
Mate slot A with tab A
Figure 3. Locating References for Log #1 Figure 3. Locating References for Log #1
Figure 5. Position Log #1 Figure 5. Position Log #1

Log #1 (SRV2158-700)

B as shown in Figure 5. When properly positioned, Log #1 will touch Tab B and sit on Log Rest. See Figure 4 to reference
the position of Tab B and the log rest .
Hearth & Home Technologies • SL-550BE-B, SL-550BE-IPI-B, DV3732SBI Log instructions • 2158-935 Rev. B • 9/09
TAB B TAB B
TAB D TAB D
Position log behind tab B
(See Figure 4 and 5 )
1 1
Tab B
Mate slot A (shown in Figure 2) with Tab A (shown in Figure 1). Position Log #1 behind Tab
LOG PLACEMENT INSTRUCTIONS
SLOT A
Figure 2. Log #1 (SRV2158-700) Figure 2. Log #1 (SRV2158-700)
Log Rest
Figure 4. Locating References for Log #1 Figure 4. Locating References for Log #1
Tab B
1
