PPC-1529/1729/2129
15"/17"/21.5" Intel® Celeron® SoC Processor J1900 Fanless
Plastic Chassis Touch Panel PC
Quick Reference Guide
nd
Ed – 29 March, 2016
2
Copyright Notice
Copyright © 2016 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017P190A2R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-1529 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avalue Technology PPC-1529

Summary of Contents for Avalue Technology PPC-1529

  • Page 1 PPC-1529/1729/2129 15"/17"/21.5" Intel® Celeron® SoC Processor J1900 Fanless Plastic Chassis Touch Panel PC Quick Reference Guide Ed – 29 March, 2016 Copyright Notice Copyright © 2016 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017P190A2R...
  • Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.

  • Page 4: Table Of Contents

    Safety Precautions ....................5 Packing List ......................5 System Specifications ................... 6 System Overview ....................10 1.4.1 PPC-1529 Rear View ....................10 1.4.2 PPC-1729 Rear View....................10 1.4.3 PPC-2129 Rear View ....................10 System Dimensions ..................... 12 1.5.1 PPC-1529 ........................12 1.5.2 PPC-1729 ........................

  • Page 5: Getting Started

    — Audio drivers and utilities — WiFi drivers and utilities — Touch controller drivers and utilities 1 x packing set includes the followings  — 1 x power cord — 1 x AC/DC adapter 12V/5A 60W (PPC-1529/1729); 12V/7A 84W (PPC-2129) PPC-1529/1729/2129 Quick Reference Guide...

  • Page 6: System Specifications

    PS/2 KB & Mouse Serial Port 1 x COM D-sub 9 Pin USB Port 4 x USB HDMI Port 1 x HDMI Audio Port 1 x Line out (RealTek ALC892-GR) LAN Port 2 x RJ-45 6 PPC-1529/1729/2129 Quick Reference Guide...
  • Page 7 5.9 Kgs Weight White + Gray White + Gray Color Fanless Fanless Fanless Reliability EMI Test Class B Safety CE FCC Operating 0°C ~ 40°C Temperature Operating Humidity 10% to 95% @ 40°C, Non-condensing Storage Temperature -10~50°C PPC-1529/1729/2129 Quick Reference Guide...
  • Page 8 HDMI Port 1 x HDMI Audio Port 1 x Line out 2 x RJ-45 LAN Port Intel WGI211AT Optional PCB Antenna 2.4/5.0GHz Wireless LAN Antenna 2 x MiniPCIe Slot Expansion Slots Mechanical Power Type AT/ATX 8 PPC-1529/1729/2129 Quick Reference Guide...
  • Page 9 White + Gray Fanless Fanless Reliability EMI Test Class B Safety CE FCC Operating 0°C ~ 40°C Temperature 10% to 95% @ 40°C, Non-condensing Operating Humidity Storage Temperature -10~50°C Note: Specifications are subject to change without notice. PPC-1529/1729/2129 Quick Reference Guide...

  • Page 10: System Overview

    1.4 System Overview 1.4.1 PPC-1529 Rear View 1.4.2 PPC-1729 Rear View 1.4.3 PPC-2129 Rear View Connectors Label Function Note COM1 Serial port 1 connector DB-9 male connector Compact CF Type I/II Socket with Ejector Flash/COM2 10 PPC-1529/1729/2129 Quick Reference Guide...
  • Page 11 Quick Reference Guide DC IN DC Power-in connector LAN1 RJ-45 Ethernet connector 1 PS/2 keyboard & mouse connector KB/MS/LAN2 Optional 2 2 x USB 2.0 connector HDD LED Power LED Reset button Reset PPC-1529/1729/2129 Quick Reference Guide 11...

  • Page 12: System Dimensions

    PPC-1529/1729/2129 1.5 System Dimensions 1.5.1 PPC-1529 (Unit: mm) 12 PPC-1529/1729/2129 Quick Reference Guide...

  • Page 13: Ppc-1729

    Quick Reference Guide 1.5.2 PPC-1729 (Unit: mm) PPC-1529/1729/2129 Quick Reference Guide 13...

  • Page 14: Ppc-2129

    PPC-1529/1729/2129 1.5.3 PPC-2129 (Unit: mm) 14 PPC-1529/1729/2129 Quick Reference Guide...

  • Page 15: Hardware Configuration

    Quick Reference Guide 2. Hardware Configuration Please refer to EBM-BYT User’s Manual for further information.  Note: If you need more information, please visit our website: http://www.avalue.com.tw PPC-1529/1729/2129 Quick Reference Guide 15...

  • Page 16: Ppc-1529/1729/2129 Connector Setting

    PPC-1529/1729/2129 2.1 PPC-1529/1729/2129 connector setting 2.1.1 Serial port 1 connector (COM1) Signal Signal 16 PPC-1529/1729/2129 Quick Reference Guide...

  • Page 17: Installing Hard Disk & Memory

    Step 1. Unfasten 4 screws from the rear middle side of your panel. Step 2. Remove the HDD service window. Step 3. Slide HDD into its bracket until properly seated Step 4. Secure HDD by means of 4 screws. PPC-1529/1729/2129 Quick Reference Guide 17...
