Avalue Technology LPC-1009 Series Quick Reference Manual

Fanless multifunctional touch panel computer
Hide thumbs Also See for LPC-1009 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
LPC-1009/1209/1509/
1709 Series
Fanless Multifunctional Touch Panel Computer
Quick Reference Guide
Ed – 16 December 2024
th
6
Copyright Notice
Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017L090A6R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPC-1009 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology LPC-1009 Series

Summary of Contents for Avalue Technology LPC-1009 Series

  • Page 1 LPC-1009/1209/1509/ 1709 Series Fanless Multifunctional Touch Panel Computer Quick Reference Guide Ed – 16 December 2024 Copyright Notice Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017L090A6R...

  • Page 2: Declaration Of Conformity

    For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2024 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc.
  • Page 3 Quick Reference Guide to change without notice. It does not represent a commitment on the part of Avalue. This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication.
  • Page 4 LPC-1009/1209/1509/1709 Series Product Warranty (Returns & Warranties policy) 1. Purpose Avalue establishes the following maintenance specifications and operation procedures for providing the best quality of service and shortened repair time to our customers. 2. Warranty 2.1 Warranty Period Avalue endeavors to offer customers the most comprehensive post-sales services and protection;...
  • Page 5 Quick Reference Guide As for other conditions, Avalue will handle defects by way of repair. The customer will be requested to send the defective product to an Avalue authorized service center, and Avalue will return the repaired product back to the customer as soon as possible. 2.3 Ruling of an out-of-warranty defect The following situations are not included in the warranty: •...
  • Page 6 LPC-1009/1209/1509/1709 Series In case the customer can’t define the cause of problem, please contact Avalue application engineers. Sometimes when the problem can be resolved even before the customer sends back the product. On the other hand, if the customer only returns the key parts to Avalue for repair, it is necessary that the serial number of the entire unit is given in the “Problem Description”...
  • Page 7 Quick Reference Guide or other causes. Avalue reserves the right for the ruling of the aforementioned situations. • Product damage resulting from lightning, flood, earthquake or other calamities. • The warranty rules for non-Avalue products and accessories shall be in accordance with standards set up by the original supplier.

  • Page 8: Safety Instructions

    LPC-1009/1209/1509/1709 Series 4. Service Products Avalue provides service products to manage with different customer needs. Should you have any need, please consult to Avalue Sales Department. Defect Analysis Report (DAR) Avalue provides DAR (Defect Analysis Report) services aiming to elevating customer satisfaction.
  • Page 9 Quick Reference Guide avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: •...

  • Page 10: Explanation Of Graphical Symbols

    LPC-1009/1209/1509/1709 Series Explanation of Graphical Symbols A WARNING statement provides important information about a Warning potentially hazardous situation which, if not avoided, could result in death or serious injury. A CAUTION statement provides important information about a potentially hazardous situation which, if not avoided, may result Caution in minor or moderate injury to the user or patient or in damage to the equipment or other property.
  • Page 11 Quick Reference Guide Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. LPC-1009/1209/1509/1709 Series Quick Reference Guide 11...

  • Page 12: Disposing Of Your Old Product

    LPC-1009/1209/1509/1709 Series Disposing of your old product WARNING: There is danger of explosion if the battery is mishandled or incorretly replaced. Replace only with the same type of battery. Do not disassemble it or attempt to recharge it outside the system. Do not crush, puncture, dispose of in fire, short the external contacts, or expose to water or ther liquids.

  • Page 13: Table Of Contents

    Quick Reference Guide Content Getting Started ...................... 14 1.1 Safety Precautions ....................14 1.2 Packing List ......................14 1.3 System Specifications ..................... 16 1.4 System Overview ....................20 1.4.1 Top View ..........................20 1.4.2 Bottom View ........................... 20 1.5 System Dimensions ....................21 1.5.1 LPC-1009 Front and Rear side ....................

  • Page 14: Getting Started

    LPC-1009/1209/1509/1709 Series 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.
  • Page 15 Quick Reference Guide Purposes and Applications LPC series is used the Intel® Atom series (Bay Trail platform), which has stronger performance and lower power consumption. it also inherits from FPC-series strength, Modularized, Flexible Expansion, Reliability and Stability. LPC series have been passed stricter vibration and shock testing. It can be used on extreme environment like manufacture or factory.

  • Page 16: System Specifications

    LPC-1009/1209/1509/1709 Series 1.3 System Specifications Panel LPC-1009 LPC-1209 Model LCD size 10.4", 4:3 12.1", 4:3 Display type XGA TFT Resolution 1024 x 768 Pixel pitch 0.0685mm(H) x 0.2055mm(V) 0.240mm(H) x 0.240mm(V) Luminance 500 cd/m² 600 cd/m² Contrast ratio 1200 Viewing angle 88(U), 88(D), 88(L), 88(R) 70(U), 70(D), 80(L), 80(R) Response time...
  • Page 17 Quick Reference Guide Audio AC97 Codec Realtek ALC888S supports 5.1-CH Audio Audio Interface Connector: Line out Ethernet LAN Chip Dual Intel I210IT PCI-E Gigabit LAN Ethernet 10/100/1000 Base-Tx Fast Ethernet compatible Interface Mechanical & Environment Color Front Silver & Rear panel Black Mounting Wall/Stand/VESA 75 mm x 75 mm System Power...
  • Page 18 LPC-1009/1209/1509/1709 Series Panel LPC-1509 LPC-1709 Model LCD size 15", 4:3 17", 4:3 Display type SXGA Resolution 1024 x 768 1280 x 1024 Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V) Luminance 400 cd/m² 350 cd/m² Contrast ratio Viewing angle 70(U), 70(D), 80(L), 80(R ) 80(U), 80(D), 85(L), 85(R ) Response time 16 ms...
  • Page 19 Quick Reference Guide Resolution HDMI 1.4a resolutions up to 1920x1200@ 60 24bpp Dual Display LVDS + HDMI Audio AC97 Codec Realtek ALC888S supports 5.1-CH Audio Audio Connector: Line out Interface Ethernet LAN Chip Dual Intel I210IT PCI-E Gigabit LAN Ethernet 10/100/1000 Base-Tx Fast Ethernet compatible Interface Mechanical &...

  • Page 20: System Overview

    LPC-1009/1209/1509/1709 Series 1.4 System Overview 1.4.1 Top View LPC-1009/1209 LPC-1509/1709 1.4.2 Bottom View Connectors Label Function Note POWER Power on button Compact CF Type I/II Socket with Ejector Optional for 2 COM port Flash/COM2 DB-9 male connector COM1 Serial port 1 connector LINE OUT Line-out audio jack 1 x USB 2.0 connector...

  • Page 21: System Dimensions

    Quick Reference Guide 1.5 System Dimensions 1.5.1 LPC-1009 Front and Rear side (Unit: mm) LPC-1009/1209/1509/1709 Series Quick Reference Guide 21...

  • Page 22: Lpc-1209 Front And Rear Side

    LPC-1009/1209/1509/1709 Series 1.5.2 LPC-1209 Front and Rear side (Unit: mm) 22 LPC-1009/1209/1509/1709 Series Quick Reference Guide...

  • Page 23: Lpc-1509 Front And Rear Side

    Quick Reference Guide 1.5.3 LPC-1509 Front and Rear side (Unit: mm) LPC-1009/1209/1509/1709 Series Quick Reference Guide 23...

  • Page 24: Lpc-1709 Front And Rear Side

    LPC-1009/1209/1509/1709 Series 1.5.4 LPC-1709 Front and Rear side (Unit: mm) 24 LPC-1009/1209/1509/1709 Series Quick Reference Guide...

  • Page 25: Hardware Configuration

    Quick Reference Guide 2. Hardware Configuration For advanced information, please refer to: 1- EBM-BYT User’s Manual Note: If you need more information, please visit our website: www.avalue.com LPC-1009/1209/1509/1709 Series Quick Reference Guide 25...

  • Page 26: Serial Port 1 Connector (Com1)

    LPC-1009/1209/1509/1709 Series 1.1. LPC-1009/1209/1509/1709 Series connector mapping 2.1.1 Serial port 1 connector (COM1) Signal PIN PIN Signal NDCDA#_485TXN NDSRA# NRXDA_485TXP NRTSA# NTXDA_485RXP NCTSA# NDTRA#_485RXN NRIA# 26 LPC-1009/1209/1509/1709 Series Quick Reference Guide...

  • Page 27: Serial Port 2 Connector (Com2)

    Quick Reference Guide 2.1.2 Serial port 2 connector (COM2) RS-232 Signal PIN PIN Signal RS-422 Signal PIN PIN Signal TxD- RxD+ TxD+ RxD- RS-485 Signal PIN PIN Signal DATA- DATA+ LPC-1009/1209/1509/1709 Series Quick Reference Guide 27...

  • Page 28: Installing Hard Disk & Memory (For Lpc-1009/1209)

    LPC-1009/1209/1509/1709 Series 2.2 Installing Hard Disk & Memory (For LPC-1009/1209) Step 1. Unfasten 6 screws from the case. Then take off the top chassis. Step 2. Insert the SODIMM into the memory socket. 28 LPC-1009/1209/1509/1709 Series Quick Reference Guide...
  • Page 29 Quick Reference Guide Step 3-1. SATA HDD Installation: By default, the SATA cables had been inserted to the according connectors. Just connect to SATA HDD with the two cables. Step 3-2. Insert the HDD into the Drive Bay. Remember to place the HDD down to the bottom exactly in order to screw the device tightly.

  • Page 30: Installing Hard Disk & Memory (For Lpc-1509/1709)

    LPC-1009/1209/1509/1709 Series 2.3 Installing Hard Disk & Memory (For LPC-1509/1709) Step 1. Memory Installation: Unfasten 6 screws from the case to take off the top chassis. Step 2. Insert the SODIMM into the memory socket. Step 3-1. HDD Installation: Unfasten 2 screws of the HDD bracket and take it off. 30 LPC-1009/1209/1509/1709 Series Quick Reference Guide...
  • Page 31 Quick Reference Guide Step 3-2. Insert the HDD into the bracket and fasten 4 screws. Step 3-3. SATA HDD Installation: By default, the SATA cables had been inserted to the according connectors. Just connect to SATA HDD with the two cables. MPCIE connector LPC-1009/1209/1509/1709 Series Quick Reference Guide 31...
  • Page 32 LPC-1009/1209/1509/1709 Series Step 3-4. Insert the HDD back and fasten 2 screws. Step 4. Place back the chassis with 6 screws locked. 32 LPC-1009/1209/1509/1709 Series Quick Reference Guide...
