- Page 1 FPC 08W2x Series 8" WSVGA TFT Fanless Touch Panel PC Quick Reference Guide Ed – 16 December 2024 Copyright Notice Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017F850A2R...
-
Page 2: Declaration Of Conformity
For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2024 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc. - Page 3 Quick Reference Guide to change without notice. It does not represent a commitment on the part of Avalue. This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication.
- Page 4 FPC-08W2x Series Product Warranty (Returns & Warranties policy) 1. Purpose Avalue establishes the following maintenance specifications and operation procedures for providing the best quality of service and shortened repair time to our customers. 2. Warranty 2.1 Warranty Period Avalue endeavors to offer customers the most comprehensive post-sales services and protection;...
- Page 5 Quick Reference Guide As for other conditions, Avalue will handle defects by way of repair. The customer will be requested to send the defective product to an Avalue authorized service center, and Avalue will return the repaired product back to the customer as soon as possible. 2.3 Ruling of an out-of-warranty defect The following situations are not included in the warranty: •...
- Page 6 FPC-08W2x Series In case the customer can’t define the cause of problem, please contact Avalue application engineers. Sometimes when the problem can be resolved even before the customer sends back the product. On the other hand, if the customer only returns the key parts to Avalue for repair, it is necessary that the serial number of the entire unit is given in the “Problem Description”...
- Page 7 Quick Reference Guide or other causes. Avalue reserves the right for the ruling of the aforementioned situations. • Product damage resulting from lightning, flood, earthquake or other calamities. • The warranty rules for non-Avalue products and accessories shall be in accordance with standards set up by the original supplier.
-
Page 8: Safety Instructions
FPC-08W2x Series 4. Service Products Avalue provides service products to manage with different customer needs. Should you have any need, please consult to Avalue Sales Department. Defect Analysis Report (DAR) Avalue provides DAR (Defect Analysis Report) services aiming to elevating customer satisfaction. - Page 9 Quick Reference Guide avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: •...
-
Page 10: Explanation Of Graphical Symbols
FPC-08W2x Series Explanation of Graphical Symbols A WARNING statement provides important information about a Warning potentially hazardous situation which, if not avoided, could result in death or serious injury. A CAUTION statement provides important information about a potentially hazardous situation which, if not avoided, may result Caution in minor or moderate injury to the user or patient or in damage to the equipment or other property. - Page 11 Quick Reference Guide Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. FPC-08W2x Series Quick Reference Guide 11...
-
Page 12: Disposing Of Your Old Product
FPC-08W2x Series Disposing of your old product WARNING: There is danger of explosion if the battery is mishandled or incorretly replaced. Replace only with the same type of battery. Do not disassemble it or attempt to recharge it outside the system. Do not crush, puncture, dispose of in fire, short the external contacts, or expose to water or ther liquids. -
Page 13: Table Of Contents
Quick Reference Guide Content Getting Started ......................14 Safety Precautions ....................14 Packing List ......................14 System Specifications ..................16 System Overview ....................22 System Dimensions ..................... 25 1.5.1 FPC-08W21 ..........................25 1.5.2 FPC-08W24 ..........................26 1.5.3 FPC-08W25 ..........................27 1.5.4 FPC-08W27 .......................... -
Page 14: Getting Started
FPC-08W2x Series 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. - Page 15 Quick Reference Guide Purposes and Applications FPC-08W2x Series is used the Intel® Atom series, which has stronger performance and lower power consumption. it also inherits from FPC-series strength, Modularized, Flexible Expansion, Reliability and Stability. FPC series have been passed stricter vibration and shock testing. It can be used on extreme environment like manufacture or factory.
-
Page 16: System Specifications
FPC-08W2x Series 1.3 System Specifications Panel Specifications FPC-08W21 FPC-08W24 LCD size 8" Display type WSVGA TFT Resolution 1024 x 600 Color 256K Pixel pitch 0.1725mm(H) x 0.1656mm(V) Luminance 500 cd/m² Contrast ratio Viewing angle Response time 20 ms Backlight Touch Type 5-wire Resistive Touch Light Transmission USB onboard Touch Controller... - Page 17 Quick Reference Guide Rear Panel I/O Serial Port 1 x RS-232, 1 x RS-232 or optional RS-422/485 Ethernet Dual Realtek RTL8101L LAN Dual Marvell 88E8053 GigaLAN Optional USB WiFi 802.11 b/g WIFI Optional USB WiFi 802.11 b/g (occupy one USB port) 1 x DB-15 HDMI Audio...
- Page 18 FPC-08W2x Series Panel Specifications FPC-08W25 FPC-08W27 LCD size 8" Display type WSVGA TFT Resolution 1024 x 600 Color 256K Pixel pitch 0.1725mm(H) x 0.1656mm(V) Luminance 500 cd/m² Contrast ratio Viewing angle Response time 20 ms Backlight Touch Type 5-wire Resistive Touch Light Transmission USB onboard Touch Controller Touch Interface...
- Page 19 Quick Reference Guide Rear Panel I/O Serial Port 1 x RS-232, 1 x RS-232 or optional RS-422/485 Ethernet Dual Intel 82574L Gigabit LAN Dual Intel® 82574L Gigabit LAN WIFI Optional USB WiFi 802.11 b/g Optional USB WiFi 802.11 b/g 1 x DB-15 HDMI 1 x HDMI 1 x Line-out, 1 x Mic-in (Realtek...
- Page 20 FPC-08W2x Series Panel Specifications FPC-08W29 LCD size 8" Display type WSVGA TFT Resolution 1024 x 600 Pixel pitch 0.1725mm(W) x 0.1656mm(H) Luminance 500 cd/m² Contrast ratio Viewing angle 70 (U), 75 (D), 75 (L), 75 (R) Response time 20 ms Backlight Touch Type 5 Wires resistive...
- Page 21 Quick Reference Guide Power Requirement +12V ~ +26V Single Power ATX Support S0, S1, S3, S4, S5 ACPI ACPI 3.0 Compliant Power Type AT/ATX (ATX is default setting) Input: 100 ~ 240Vac/ 50 ~ 60Hz Adapter Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter Mechanical &...
-
Page 22: System Overview
FPC-08W2x Series 1.4 System Overview 1.4.1 FPC-08W2x Series Right View 1.4.2 FPC-08W21 Rear View 1.4.3 FPC-08W24 Rear View 1.4.4 FPC-08W25 Rear View 22 FPC-08W2x Series Quick Reference Guide... - Page 23 Quick Reference Guide 1.4.5 FPC-08W27 Rear View 1.4.6 FPC-08W29 Rear View Connectors Label Function Note CompactFlash Type I/II socket with cover Serial port 1 & 2 (FPC-08W21, FPC-08W24, FPC-08W25, and FPC-08W27 Optional RS-422/485 for COM2) DB-9 male connector (FPC-08W29 Optional RS-422/485 for COM1 by BIOS setting) DC in DC Power-in connector...
- Page 24 FPC-08W2x Series Mic In Mic-in audio jack HDD Indicator HDMI HDMI connector (FPC-08W27, FPC-08W29) Power LED Reset Reset button CRT connector DB-15 female connector Power Power switch 24 FPC-08W2x Series Quick Reference Guide...
-
Page 25: System Dimensions
Quick Reference Guide 1.5 System Dimensions 1.5.1 FPC-08W21 (Unit: mm) FPC-08W2x Series Quick Reference Guide 25... -
Page 26: Fpc-08W24
FPC-08W2x Series 1.5.2 FPC-08W24 (Unit: mm) 26 FPC-08W2x Series Quick Reference Guide... -
Page 27: Fpc-08W25
Quick Reference Guide 1.5.3 FPC-08W25 (Unit: mm) FPC-08W2x Series Quick Reference Guide 27... -
Page 28: Fpc-08W27
FPC-08W2x Series 1.5.4 FPC-08W27 (Unit: mm) 28 FPC-08W2x Series Quick Reference Guide... -
Page 29: Fpc-08W29
Quick Reference Guide 1.5.5 FPC-08W29 (Unit: mm) FPC-08W2x Series Quick Reference Guide 29... -
Page 30: Hardware Configuration
FPC-08W2x Series 2. Hardware Configuration Please refer to ECM-LX800D, ECM-945GSE, ECM-PNV, ECM-CDV ⚫ and ECM-BYT User’s Manual for further information. Note: If you need more information, please visit our website: www.avalue.com 30 FPC-08W2x Series Quick Reference Guide... -
Page 31: Fpc 08W21/08W24/08W25/08W27 Connector Setting
Quick Reference Guide 2.1 FPC 08W21/08W24/08W25/08W27 connector setting 2.1.1 VGA connector (VGA) PIN Signal PIN Signal PIN Signal DATA 13 HSYNC VSYNC 2.1.2 External Serial Port 1 connector (COM1) Signal Signal DCD# DSR# RXDD# RTS# TXDD# CTS# DTR# FPC-08W2x Series Quick Reference Guide 31... -
Page 32: External Serial Port 2 Connector (Com2)
FPC-08W2x Series 2.1.3 External Serial Port 2 connector (COM2) In RS-232 Mode Signal Signal DCD# DSR# RXDD# RTS# TXDD# CTS# DTR# In RS-422 Mode Signal Signal TxD1- RxD1- TxD1+ RxD1+ In RS-485 Mode Signal Signal DATA1- DATA1+ 32 FPC-08W2x Series Quick Reference Guide... -
Page 33: Fpc 08W29 Connector Setting
Quick Reference Guide 2.2 FPC 08W29 connector setting 2.1.1 VGA connector (VGA) PIN Signal PIN Signal PIN Signal DATA 13 HSYNC VSYNC 2.2.1 External Serial Port 1 connector (COM1) Signal Signal NDCDA#_485TXN NDSRA# Note : NRXDA_485TXP RTSA# COM1 support RS-422/485 by BIOS setting. NTXDA_485RXP NCTSA# NDTRA#_485RXN... -
Page 34: Installing Memory
FPC-08W2x Series 2.3 Installing Memory (FPC-08W21, FPC-08W24) (FPC-08W25, FPC-08W27) Step 1. Unfasten 8 screws from the case to take off the top chassis. 34 FPC-08W2x Series Quick Reference Guide... - Page 35 Quick Reference Guide Step 2. Remove 8 screws as above and have the box pc and board separated. Step 3. Insert the SODIMM into the memory socket. FPC-08W2x Series Quick Reference Guide 35...
-
Page 36: Installing Cf Card
FPC-08W2x Series 2.4 Installing CF Card Step 1. Unlock 2 screws from the rear side of the panel PC as above. Step 2. Put the CF card into the socket and fasten 2 screws back. 36 FPC-08W2x Series Quick Reference Guide...
