FPC-1736
17" Flexibility Multifunctional Touch Panel PC
Quick Reference Guide
Ed – 03 November 2022
st
1
Copyright Notice
Copyright  2022 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017F176A0R

Advertisement

Table of Contents
loading

Related Manuals for Avalue Technology FPC-1736

Summary of Contents for Avalue Technology FPC-1736

  • Page 1 FPC-1736 17” Flexibility Multifunctional Touch Panel PC Quick Reference Guide Ed – 03 November 2022 Copyright Notice Copyright  2022 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017F176A0R...
  • Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.

  • Page 4: Table Of Contents

    2.5.17 PS/2 Keyboard & Mouse Header (PS2KBMS) ..............27 2.5.18 SMBUS Header (SMBUS) ..................... 27 2.5.19 Front Panel Audio Header (*FP_AUDIO) ................28 2.5.20 3W Amplifier Wafer (*SPEAK_CON) ..................28 2.5.21 RS232 Serial Port Header (COM1/2/3/4) ................29 4 FPC-1736 Quick Reference Guide...
  • Page 5 Function Keys......................34 Getting Help ......................34 Menu Bars ......................35 Main Menu ......................35 Advanced Menu ....................36 Chipset Menu ......................46 Security Menu......................48 3-10 Boot Menu ......................50 3-11 Save & Exit Menu ....................51 FPC-1736 Quick Reference Guide...

  • Page 6: Getting Started

    Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées selon les instructions 1.2 Packing List 1 x FPC-1736 Panel PC  1 x Power Adapter ...

  • Page 7: System Specifications

    Video Port 1 x VGA *Support one type of video function at a time Audio Port 1 x Line-out, 1 x Mic-in 1 x Intel i219-V Gigabit Ethernet LAN Port 1 x Intel i225-V 2.5 Gigabit Ethernet FPC-1736 Quick Reference Guide...
  • Page 8 2 Test frequency : 5~500 Hz 3 Test axis : X,Y and Z axis 4 Test time : 30 minutes per each axis 5 IEC 60068-2-64 Test Fh Mechanical Shock 1 Wave from : Half Sine wave 8 FPC-1736 Quick Reference Guide...
  • Page 9 *Air flow=0.7 m/s Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Storage -20°C ~ 60°C Temperature Power Max. load 101.21 W with intel core i7-9700E/4GB/64GB(M.2 SSD)/64BG(2.5” Consumption SSD), DC-in 19V Note: Specifications are subject to change without notice. FPC-1736 Quick Reference Guide...

  • Page 10: System Overview

    4 x USB 3.0 connector 1 x USB 2.0 for USB dongle in the USB 2.0 enclosure 3 x USB 2.0 (Optional) LAN1 RJ-45 Ethernet connector 1 RJ-45 Ethernet connector 2 LAN2 VGA connector HDMI HDMI connector 10 FPC-1736 Quick Reference Guide...

  • Page 11: System Dimensions

    Quick Reference Guide 1.5 System Dimensions (Unit: mm) FPC-1736 Quick Reference Guide 11...

  • Page 12: Hardware Configuration

    FPC-1736 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw 12 FPC-1736 Quick Reference Guide...

  • Page 13: Serial Port Connector 1/2/3 (Com)

    Quick Reference Guide 2.1 FPC-1736 connector mapping 2.1.1 Serial port connector 1/2/3 (COM) Signal PIN PIN Signal 2.1.2 Serial port connector 4 (COM/USB) Signal PIN PIN Signal FPC-1736 Quick Reference Guide 13...
  • Page 14 FPC-1736 2.2 Installing PCIe devices (FPC-1736) Step 1. Remove 16 screws to release the chassis cover, and remove it. 14 FPC-1736 Quick Reference Guide...
  • Page 15 Quick Reference Guide Step 2. Install the expansion module and fasten screw. FPC-1736 Quick Reference Guide 15...

  • Page 16: Motherboard Overviews

    FPC-1736 2.3 Motherboard Overviews 16 FPC-1736 Quick Reference Guide...

  • Page 17: Motherboard Jumper And Connector List

    4 x 1 header, pitch 2.00mm PS/2 Keyboard & Mouse Header 6 x 1 header, pitch 2.00mm PS2KBMS SMBUS SMBUS Header 5 x 1 header, pitch 2.00mm Front Panel Audio Header 2 x 5 header, pitch 2.00mm *FP_AUDIO FPC-1736 Quick Reference Guide 17...
  • Page 18 2 x 5 header, pitch 2.54mm LVDS Port Wafer 2 x 15 wafer, pitch 1.25mm LVDS INVERTER1 LVDS Inverter Wafer 6 x 1 wafer, pitch 2.00mm eDP Port Wafer 2 x 15 wafer, pitch 1.25mm 18 FPC-1736 Quick Reference Guide...

  • Page 19: Motherboard Jumpers & Connectors Settings

    1-2 Closed: ATX Mode Selected(Default)* 2-3 Closed: AT Mode Selected * Default *ATX Mode Selected: Press power button to power on after power input ready; AT Mode Selected: Directly power on as power input ready. FPC-1736 Quick Reference Guide 19...

  • Page 20: Me Features Select (Jp2)

    When Used, needs to enter BIOS and enable ‘Case Open Detect’ function. In this case if your case is removed, next time when you restart your computer, a message will be displayed on screen to inform you of this. 20 FPC-1736 Quick Reference Guide...

  • Page 21: Lvds Inverter Backlight Vcc Select (Jp16)

    2.5.6 LVDS Inverter Header (INVERTER1) Signal BKLT_PWR1 BKLT_PWR2 BKLT_EN BKLT_PWM GND1 GND2 Warning! Find Pin-1 location of the inverter and make sure that the installation direction is correct! Otherwise serious harm will occur to the board/display panel!! FPC-1736 Quick Reference Guide 21...

  • Page 22: Com1 Pin9 Function Select (Jp12)

    JP12COM1 Pin9 Function Select 2-4 Closed:* 3-4 Closed: Pin9=RS232,Ring Pin9=5V 6-4 Closed: * Default Pin9=12V 2.5.8 COM2 Pin9 Function Select (JP13) JP13COM2 Pin9 Function Select 2-4 Closed:* 3-4 Closed: Pin9=RS232,Ring Pin9=5V 6-4 Closed: Pin9=12V * Default 22 FPC-1736 Quick Reference Guide...

  • Page 23: Internal 12V~24V Power Connector (Dcin3)

    Quick Reference Guide 2.5.9 Internal 12V~24V Power Connector (DCIN3) Signal +12V~24V Warning: Find Pin-1 position before connecting power cable to this 2-pin power connector. WRONG INSTALLATION DIRECTION WILL DAMAGE THE BOARD!! 2.5.10 CPU Fan Connector (CPUFAN) FPC-1736 Quick Reference Guide 23...

  • Page 24: System Fan Connector (Sysfan)

    FPC-1736 2.5.11 System Fan Connector (SYSFAN) 2.5.12 SATA III Port connector (SATA1) SATA1 is a high-speed SATAIII port that supports 6GB/s transfer rate. 24 FPC-1736 Quick Reference Guide...

  • Page 25: Sata Power Out Connector (Pwrout)

    2.5.13 SATA Power Out Connector (PWROUT) Warning: Make sure that Pin-1 of compatible SATA Power connector is inserted into corresponding Pin-1 of SATAPW to avoid possible damage to the board and hard disk driver! 2.5.14 Front Panel Header (FP) FPC-1736 Quick Reference Guide 25...

  • Page 26: Usb 2.0 Port Headers (Fp_Usb1/Fp_Usb2)

    FPC-1736 2.5.15 USB 2.0 Port Headers (FP_USB1/FP_USB2) 2.5.16 USB 2.0 Port Header (FP_USB3) 26 FPC-1736 Quick Reference Guide...

  • Page 27: Ps/2 Keyboard & Mouse Header (Ps2Kbms)

    Quick Reference Guide 2.5.17 PS/2 Keyboard & Mouse Header (PS2KBMS) 2.5.18 SMBUS Header (SMBUS) FPC-1736 Quick Reference Guide 27...

  • Page 28: Front Panel Audio Header (*Fp_Audio)

    FPC-1736 2.5.19 Front Panel Audio Header (*FP_AUDIO) 2.5.20 3W Amplifier Wafer (*SPEAK_CON) Signal 28 FPC-1736 Quick Reference Guide...

  • Page 29: Rs232 Serial Port Header (Com1/2/3/4)

    Quick Reference Guide 2.5.21 RS232 Serial Port Header (COM1/2/3/4) 2.5.22 GPIO Header (GPIO) FPC-1736 Quick Reference Guide 29...

  • Page 30: Lvds Port Wafer (Lvds)

    PVCC PVCC PVCC PVCC LVDSA_DATAN0 26 25 LVDSA_DATAP0 LVDSA_DATAN1 24 23 LVDSA_DATAP1 LVDSA_DATAN2 22 21 LVDSA_DATAP2 LVDS_CLKAN LVDS_CLKAP LVDSA_DATAN3 18 17 LVDSA_DATAP3 NC/DDC_CLK NC/DDC_DATA LVDSB_DATAP0 10 LVDSB_DATAN0 LVDSB_DATAP1 LVDSB_DATAN1 LVDSB_DATAP2 LVDSB_DATAN2 LVDS_CLKBP LVDS_CLKBN LVDSB_DATAP3 LVDSB_DATAN3 30 FPC-1736 Quick Reference Guide...

  • Page 31: Lvds Panel Power Vcc Select (Jp5)

    Quick Reference Guide 2.5.24 LVDS Panel Power VCC Select (JP5) JP5LVDS Panel Power VCC Select 2-4 Closed: 3-4 Closed:* VCC=3.3V; VCC=5V; 6-4 Closed: VCC=12V. * Default FPC-1736 Quick Reference Guide 31...

  • Page 32: Bios Setup

    FPC-1736 3.BIOS Setup 32 FPC-1736 Quick Reference Guide...

  • Page 33: Entering Setup

    <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to Press <Del> to enter Setup; press < F7> to enter pop-up Boot menu. FPC-1736 Quick Reference Guide 33...

  • Page 34: Bios Menu Screen

     [F4]: Save & Exit.  Press <Esc> to exit from BIOS Setup. 3-4 Getting Help Main Menu The on-line description of the highlighted setup function is displayed at the top right corner the screen. 34 FPC-1736 Quick Reference Guide...

  • Page 35: Menu Bars

    <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the date. Please use [Tab] to switch between date elements. System Time Set the time. Please use [Tab] to switch between time elements. FPC-1736 Quick Reference Guide 35...

  • Page 36: Advanced Menu

    When set as [Enabled], a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. Intel(R) SpeedStep(tm) This item allows more than two frequency ranges to be supported. The optional settings: [Disabled]; [Enabled]. C states 36 FPC-1736 Quick Reference Guide...
  • Page 37 Use this item to configure Management Engine Technology parameters. Press [Enter] to make settings for ‘ME FW Image RE-Flash’. ME FW Image Re-Flash Use this item to enable or disable ME FW Image Re-Flash function. The optional settings: [Disabled]; [Enabled]. FPC-1736 Quick Reference Guide 37...
  • Page 38 When set as [Enabled], system will wake on the current time + increased minute(s). Wake-up Minute Increase Use this item to select 1-60 PS2 KB/MS Wake-up Use this item to enable or disable PS2 KB/MS wake-up from S3/S4/S5. 38 FPC-1736 Quick Reference Guide...
  • Page 39 Use this item to enable or disable serial port (COM). The optional settings: [Disabled]; [Enabled]. Press [Enter] to make settings for the following sub-items: Device Settings Change Settings Use this item to select an optimal setting for super IO device. Changing setting may FPC-1736 Quick Reference Guide 39...
  • Page 40 User can select a value in the range of [10] to [255] seconds when ‘WatchDog Reset Timer Unit’ set as [Sec]; or in the range of [1] to [255] minutes when ‘WatchDog Reset Timer Unit ’ set as [Min]. WatchDog Reset Timer Unit The optional settings are: [Sec.]; [Min.]. 40 FPC-1736 Quick Reference Guide...
  • Page 41 The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. Press [Enter] to make settings for the following items: Terminal Type FPC-1736 Quick Reference Guide 41...
  • Page 42 With this mode enable only text will be sent. This is to capture Terminal data. The optional settings: [Disabled]; [Enabled]. Resolution 100x31 Use this item to enable or disable extended terminal resolution. The optional settings: [Disabled]; [Enabled]. Putty KeyPad Use this item to select FunctionKey and KeyPad on Putty. 42 FPC-1736 Quick Reference Guide...
  • Page 43 Terminal Type/Emulation. Bits per second Use this item to select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. FPC-1736 Quick Reference Guide 43...
  • Page 44 The optional settings are: [1 sec]; [5 sec]; [10 sec]; [20 sec]. Device reset time-out Use this item to set USB mass storage device start unit command time-out. The optional settings are: [10 sec]; [20 sec]; [30 sec]; [40 sec]. Device power-up delay 44 FPC-1736 Quick Reference Guide...
  • Page 45 Option ROM execution Network This option controls the execution of UEFI and Legacy PXE OpROM. The optional settings are: [Do not launch]; [Legacy]. Storage This option controls the execution of UEFI and Legacy Storage OpROM. FPC-1736 Quick Reference Guide 45...

  • Page 46: Chipset Menu

    Use this item to enable or disable VT-d capability. The optional settings are: [Enabled]; [Disabled]. ► Memory Configuration Press [Enter] to view brief information for the working memory module. ► Graphics Configuration Press [Enter] to make further settings for Graphics Configuration. Graphics Configuration 46 FPC-1736 Quick Reference Guide...
  • Page 47 The optional settings are: [Disabled]; [Enabled]. [Disabled]: HDA will be unconditionally disabled. [Enabled]: HDA will be unconditionally enabled. Onboard Lan1 Controller Use this item to enable or disable corresponding onboard NIC device or controller. The optional settings are: [Disabled]; [Enabled]. FPC-1736 Quick Reference Guide 47...

  • Page 48: Security Menu

    Security menu allow users to change administrator password and user password settings. Administrator Password If there is no password present on system, please press [Enter] to create new administrator password. If password is present on system, please press [Enter] to verify old password 48 FPC-1736 Quick Reference Guide...
  • Page 49 Use this item to delete all Secure Boot key databases from NVRAM.  Export Secure Boot variables Use this item to copy NVRAM content of Secure Boot variables to files in a root folder on a file system device. FPC-1736 Quick Reference Guide 49...

  • Page 50: Boot Menu

    1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_ CERT_X509 (DER encoded) c) EFI_ CERT_RSA2048 (bin) d) EFI_ CERT_SHAXXX (bin) 2. Authenticated UEFI Variable 3. EFI PE/COFF Image (SHA256) Key Source: Factory, External, Mixed. 3-10 Boot Menu 50 FPC-1736 Quick Reference Guide...

  • Page 51: Save & Exit Menu

    Use this item to restore /load default values for all the setup options. Save as User Defaults Use this item to save the changes done so far as user defaults. Restore User Defaults Use this item to restore the user defaults to all the setup options. FPC-1736 Quick Reference Guide 51...
