Secure the Center rails at both ends using

eight (8) M6x10 Machine screws (part 13), four

(4) per side. Ensure all eight (8) Machine screws

hit the metal Crossbar rails to prevent them

from sliding.

Choose the screw to fasten your frame to your desktop.

If your desktop does not have metal threaded inserts,

use the #10x5/8'' Wood screws (part 14-a)

If your desktop does have metal threaded inserts,

use the #10-24x5/8'' Machine screws (part 14-b)

Double-check that the frame is properly positioned

on the underside of the desktop.

Attach the frame assembly to the underside of the

desktop using eight (8) of the screws that you have chosen.

3 per Side bracket

1 per Crossbar end

Turn the assembled table right-side up. With two people, grab the table by the frame and desktop

equally, and turn the table right-side up. Adjust the Leveling studs (part 9) on the Feet (part 2) as needed.

5. PLACEMENT

Following table assembly, adjust the Leveling studs or casters (sold separately) on the feet so that the

table is level and does not shift its position.

When moving the table, if casters are not installed, use a two-person lift and lift the table so that it can be

moved without dragging. Dragging the table may cause the frame and screws to pull loose from the desktop.

When moving the table, DO NOT lift the table by the desktop alone, or the frame, alone. Support both the

frame and the desktop equally. Favoring one over the other can stress the fasteners connecting the table

frame to the desktop. Lower the table completely and lift the table by grasping the frame.

6. TECHNICAL SPECIFICATIONS

Height

Width Range

Weight Capacity 355 lbs

Copyright Notice: This guide is a component of the UPLIFT Desk™. This guide is a part of the scope of delivery, even if the item is resold. This guide is also available on the UPLIFT

Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other published form without the prior written consent of UPLIFT Desk.

These instructions are subject to United States copyright law.

6 total

2 total

28" (without desktop)

42.125" min - 74.75" max
