Uplift Desk Intuition Ergonomic Chair CHR472 Manual

Intuition Ergonomic Chair
SKU: CHR472

Package Contents

Casters (qty 5) Base
m6x17 m8x20 m6x17
M6x17mm Screw (qty 2) M8x20mm Screw (qty 3)
m8x32
Cylinder
m8x20 m6x17 m8x20
M8x32mm Screw (qty 2)
m8x32
split lock washer split lock washer
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com
Seat Back
m6x17 m8x20
Split Lock Washer (qty 5)
m8x32 m8x32
split lock washer

STEP 1

A. Be cautious around the small end of the Cylinder to
avoid getting grease on you or your clothes.
B. With the Base turned upside down, insert the Caster
stems into the holes in the Base, and press them
firmly to secure them in place.
C. Flip the Base, so the Casters are on the floor, and
insert the Cylinder into the Base in the orientation
shown with the smaller diameter end up.

STEP 2

A. Place the Seat upside down on the edge of a stable
surface, such as a table.
B. Insert the tab on the Seat into the slot on the Back
and line up the holes on each. Have a friend help keep
the Seat steady while you attach the Back to the Seat
with three M8x20mm Screws and three Split Lock
Washers. Start all screws loosely, then tighten them
all using the Allen wrench.

STEP 3

A. Insert the Right Arm into the arm receiver on the Seat
as shown. The arms should angle towards the front of
the chair when installed with the height adjustment
points facing outward.
B. With one M8x32mm Machine Screw and one Split
Lock Washer, fasten the Arm to the Seat through the
opening at the bottom of the Arm using the Allen
Wrench to tighten the Screw. Repeat this process for
attaching the Left Arm.
Arms
Screw Cover
split lock washer
Headrest
Allen Wrench
