Normal/Reverse Scan Select

JP11
2-3*
1-2

Note: Only specific LCD panels support these features

LCD Resolution

JP13 JP14 JP15
1-2 1-2 2-3
1-2 1-2 2-3
1-2 1-2 1-2
1-2 1-2 1-2
1-2 1-2 1-2

CRT/LCD Select

JP17
1-2*
2-3 CRT Only (Node Box Configuration)
HDD/CDROM Settings

SATA Mode Select

JP18
1-2
2-3*

IDE1 Connector - Master/Slave Mode

JP19 IDE Master/ Slave Select
1-2
2-3*
Note: Affective only when drive is physically jumpered for Cable Select
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Scan Mode
Normal Scan
Reverse Scan
JP16 Display Size
2-3 15"
1-2 17"
2-3 12"
1-2 19"
2-3 N/A
Display Select
CRT & LCD
HDD Mode
Reserved
IDE Mode
Master
Slave
72
Appendix D - AIM4 Jumper Settings
LCD Resolution
1024 X 768
1280 X 1024
800 X 600
1600 X 1200
Node Box Operation
