4600 Series Flat Panel Industrial PC
4612KPM(T)
F/A Key LED Off (Function Mode)
4615KPM(T)
Description
Keyboard
of Key
Equivalent
PF12 / )
F32
PF13 / ?
F33
PF14 / ^
F34
PF15 / %
F35
PF16 / $
F36
PF17 / @
F37
PF18 / <
F38
PF19 / >
F39
PF20 / ~
F40
1
CTRL
CTRL
1
SHIFT
SHIFT
ESC
ESC
1
ALT
ALT
TAB
TAB
DEL
DEL
F/A
SPACE
SPACE
BACKSPACE
BACKSPAC
E
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
.
.
0
0
=
=
PgUp
PgUp
up arr
up arr
2
+
+
left arr
left arr
HOME
HOME
right arr
right arr
PgDn
PgDn
down arr
down arr
2
-
-
1
ENTER
ENTER
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 3-6. Default Keypad Keycodes
Make
Break Codes
Codes
11 06
F0 06 F0 11
11 04
F0 04 F0 11
11 0C
F0 0C F0 11
11 03
F0 03 F0 11
11 0B
F0 0B F0 11
11 83
F0 83 F0 11
11 0A
F0 0A F0 11
11 01
F0 01 F0 11
11 09
F0 09 F0 11
14
F0 14
12
F0 12
76
F0 76
11
F0 11
0D
F0 0D
E0 12 E0 71
E0 F0 71 E0 F0 12
29
F0 29
66
F0 66
16
F0 16
1E
F0 1E
26
F0 26
25
F0 25
2E
F0 2E
36
F0 36
3D
F0 3D
3E
F0 3E
46
F0 46
49
F0 49
45
F0 45
55
F0 55
E0 12 E0 7D
E0 F0 7D E0 F0 12
E0 12 E0 75
E0 F0 75 E0 F0 12
79
F0 79
E0 12 E0 6B
E0 F0 6B E0 F0 12
E0 12 E0 6C
E0 F0 6C E0 F0 12
E0 12 E0 74
E0 F0 74 E0 F0 12
E0 12 E0 7A
E0 F0 7A E0 F0 12
E0 12 E0 72
E0 F0 72 E0 F0 12
7B
F0 7B
5A
F0 5A
46
Chapter 3 – Keypad Utility Program
F/A Key LED On (Alpha Mode)
Keyboard
Make
Break Codes
Equivalent
Codes
)
12 45
F0 12 F0 45
?
12 4A
F0 12 F0 4A
^
12 36
F0 12 F0 36
%
12 2E
F0 12 F0 2E
$
12 25
F0 12 F0 25
@
12 1E
F0 12 F0 1E
<
12 41
F0 12 F0 41
>
12 49
F0 12 F0 49
~
12 0E
F0 12 F0 0E
CTRL
14
F0 14
SHIFT
12
F0 12
ESC
76
F0 76
ALT
11
F0 11
TAB
0D
F0 0D
DEL
E0 12 E0 71
E0 F0 71 E0 F0 12
SPACE
29
F0 29
BACKSPAC
66
F0 66
E
1
16
F0 16
2
1E
F0 1E
3
26
F0 26
4
25
F0 25
5
2E
F0 2E
6
36
F0 36
7
3D
F0 3D
8
3E
F0 3E
9
46
F0 46
.
49
F0 49
0
45
F0 45
=
55
F0 55
PgUp
E0 12 E0 7D
E0 F0 7D E0 F0 12
up arr
E0 12 E0 75
E0 F0 75 E0 F0 12
+
79
F0 79
left arr
E0 12 E0 6B
E0 F0 6B E0 F0 12
HOME
E0 12 E0 6C
E0 F0 6C E0 F0 12
right arr
E0 12 E0 74
E0 F0 74 E0 F0 12
PgDn
E0 12 E0 7A
E0 F0 7A E0 F0 12
down arr
E0 12 E0 72
E0 F0 72 E0 F0 12
-
7B
F0 7B
ENTER
5A
F0 5A
