Com4; Vga Connector - Xycom 4600 Series User Manual

(JP1) shall be in position 1-2 in order to activate the Reset function. The PB_RESET
pin shall be switched to GND to reset the entire board.

COM4

The following table lists the signal definitions for the COM4 DB-9 connector.
Note: COM4 to be employed when using a UPS type power supply containing
RS-232 monitoring capability.

VGA Connector

The following table lists the signal definitions for the VGA DB-15 connector.
Pin
1
2
3
4
5
6
7
8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table C - 8. COM4 Connector Pinout
Pin
1
2
3
4
5
6
7
8
9
10
Table C - 9. VGA Connector Pinout
Signal
RED
GREEN
BLUE
NC
ORB_GND
ORB_GND
ORB_GND
ORB_GND
70
Signal
DCD4
DSR4
RXD4
RTS4
TXD4
CTS4
DTR4
RI4
GND
NC
Pin Signal
9 Fused VCC
10 ORB_GND
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
Appendix C - Pinouts
144732 (C)
