4600 Series Flat Panel Industrial PC
The download.dld file was created after the last keypad programming process.
This includes both new programming and reprogramming the keypad to the
factory default settings.

Keypad Scan Codes

The utility's default keypad keycodes are listed in the following table.
4612KPM(T) F/A Key LED Off (Function Mode)
4615KPM(T)
Description Keyboard
of Key Equivalent
PF1 / A F21
PF2 / B F22
PF3 / C F23
PF4 / D F24
PF5 / E F25
PF6 / F F26
PF7 / G F27
PF8 / H F28
PF9 / I F29
PF10 / J F30
F1 / K F1
F2 / L F2
F3 / M F3
F4 / N F4
F5 / O F5
F6 / P F6
F7 / Q F7
F8 / R F8
F9 / S F9
F10 / T F10
F11 / U F11
F12 / V F12
F13 / W F13
F14 / X F14
F15 / Y F15
F16 / Z F16
F17 / : F17
F18 / / F18
F19 / \ F19
F20 / * F20
PF11 / ( F31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 3-6. Default Keypad Keycodes
Make Break Codes
Codes
14 05 F0 05 F0 14
14 06 F0 06 F0 14
14 04 F0 04 F0 14
14 0C F0 0C F0 14
14 03 F0 03 F0 14
14 0B F0 0B F0 14
14 83 F0 83 F0 14
14 0A F0 0A F0 14
14 01 F0 01 F0 14
14 09 F0 09 F0 14
05 F0 05
06 F0 06
04 F0 04
0C F0 0C
03 F0 03
0B F0 0B
83 F0 83
0A F0 0A
01 F0 01
09 F0 09
12 05 F0 05 F0 12
12 06 F0 06 F0 12
12 04 F0 04 F0 12
12 0C F0 0C F0 12
12 03 F0 03 F0 12
12 0B F0 0B F0 12
12 83 F0 83 F0 12
12 0A F0 0A F0 12
12 01 F0 01 F0 12
12 09 F0 09 F0 12
11 05 F0 05 F0 11
45
Chapter 3 – Keypad Utility Program
Note
F/A Key LED On (Alpha Mode)
Keyboard Make
Equivalent Codes
A 1C
B 32
C 21
D 23
E 24
F 2B
G 34
H 33
I 43
J 3B
K 42
L 4B
M 3A
N 31
O 44
P 4D
Q 15
R 2D
S 1B
T 2C
U 3C
V 2A
W 1D
X 22
Y 35
Z 1A
: 12 4C
/ 4A
\ 5D
* 12 3E
( 12 46
Break Codes
F0 1C
F0 32
F0 21
F0 23
F0 24
F0 2B
F0 34
F0 33
F0 43
F0 3B
F0 42
F0 4B
F0 3A
F0 31
F0 44
F0 4D
F0 15
F0 2D
F0 1B
F0 2C
F0 3C
F0 2A
F0 1D
F0 22
F0 35
F0 1A
F0 12 F0 4C
F0 4A
F0 5D
F0 12 F0 3E
F0 12 F0 46
