Appendix A – Technical Specifications

Hardware Specifications

Table A - 1 lists the hardware specifications for the 4612T, 4612KPM(T), 4615T
and 4615KPM(T).
Characteristic
Mechanical
4612T
Height
11.20"
Width
13.20"
Depth
7.36"
6.36"
1.00" front panel protrusion
Weight
16 lb
Electrical
AC
Power Supply 250 watts
Four available expansion slots:
Passive one ½ length PCI
Backplane two ¾ length PCI
one ¾ length PCI or ISA
+3.3 V
+5 V
Available
–5 V
Power
+12 V
(for expansion
–12 V
by user)
Mounting Panel Mount or 19" rack with optional filler plate.
Flat Panel 12.1" TFT active color display
UL
UL
Agency
cUL CSA C22.2, No. 142 (Listed)
Approvals
cUL CSA C22.2, No. 213 (Listed)
Regulatory FCC
Compliance CE
EMI
IMMUNITY
SAFETY
HARMONICS EN61000-3-2, Class A
FLICKER
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table A - 1. Hardware Specifications
4612
4612KPM(T)
Front Panel 12.45"
Front Panel 6.70"
overall 7.40"
behind front panel 6.40"
1.00"
17 lb
100-240 VAC
4.00A maximum
4.00A maximum
160mA maximum
3.00A maximum
240mA maximum
508 (Listed)
1604 (Listed)
47 CFR, Part 15, Class A
EN55022, Class A
EN61000–6-2
EN60950
EN61000-3-3
Specification
4615T
12.62" Front Panel
16.59" Front Panel
7.64" overall
6.64" behind front panel
1.00" front panel protrusion 1.00"
25 lb
50-60 Hz 1.0A maximum
250 watts
+3.3V 4.00A maximum
+5V 4.00A maximum
–5V 160mA maximum
+12V 3.00A maximum
–12V 240mA maximum
15" TFT active color display
63
4615
4615KPM(T)
13.97"
19.00"
7.64"
6.64"
26 lb
.
144732 (C)
