- Page 1 PA25609A01 PES197 & PES197/E Rev. 01 7-2009 PORTABLE EMBOSSING SYSTEM © Panduit Corp. 2009 Panduit Corp. Tel.: 888-506-5400, ext. 3255 Website: www.panduit.com Fax: (630) 759-7532 Email: cs@panduit.com For Regional Contact Information See Page 17...
-
Page 2: Table Of Contents
OILING THE TROLLEY TRACK AND CLAMP GUIDE ............16 CONTACT INFORMATION • For Technical Support : ... 17 NOTE: In the interest of higher quality and value, PANDUIT products are continually being improved and updated. Consequently, pictures may vary from the enclosed product. -
Page 3: Setup And Installation Guide
PES197 and PES197/E: ENGLISH SETUP and INSTALLATION GUIDE UNPACKING The machine is delivered in a wooden packing case. This is due to its dimensions and weight and avoids the risk of damage to the machine. WARNING! THE MACHINE & CRATE WEIGHS lbs. -
Page 4: Checking The Accessories
PES197 and PES197/E: ENGLISH CHECKING THE ACCESSORIES Before installing the machine the operator is advised to check that all the accessories are present and that none have been damaged during the transport. If any single element has been damaged the general working of the machine can be compromised. -
Page 5: Connecting Cables
Connect the AC cable to the rear input of the machine and to the proper AC source. Be sure to verify the power required. Identification Plate PES197 supplied with UL Plate PES197/E supplied with CE Plate Serial socket for... -
Page 6: Install Software For The Usb To Serial Adapter (If Needed)
PES197 and PES197/E: ENGLISH SOFTWARE INSTALLATION Insert the E Installation CD in the CD ROM driver. NOTE: If the CD ROM driver does not launch the Autorun.exe file automatically, ® from the START menu of Windows , select Run and digit: X:\Autorun.exe substituting the “X”... -
Page 7: Introduction
PES197 and PES197/E: ENGLISH INTRODUCTION The PANDUIT PES197 (110V) and PES197/E (220V) is an automatic personalization system for metal marker plates. It is computer operated and runs off of PANDUIT E software. (e.g.: PC compatible). The PANDUIT PES197 machines stamp exclusively PANDUIT MMP350, MMP350H and MMP350W38 Metal Marker Plates. -
Page 8: System Specifications
Listings in ( ) are metric. Power Supply 117V 60Hz PES197 Operating +50° +95° F (+10° +35° C) – ÷ 230 V 50 Hz PES197/E Temperature Current Absorption 4 A max Relative Humidity – Absorbed Power 250 W Storing +32°... - Page 9 The machine has labels that indicate any danger areas. The meanings of these labels are explained below. PANDUIT cannot be held responsible for the consequences of not abiding by these principles when using the machine. Therefore, in the case of breakdown, please call for Technical Assistance.
-
Page 10: Machine Setup For Producing Plates
PES197 and PES197/E: ENGLISH MACHINE SETUP FOR PRODUCING PLATES • Unlock cover with cover key and open machine cover. (The cover will “latch” into the open position.) • Insert plates for embossing in the loader on the right side of the machine. -
Page 11: Hopper Installation
PES197 and PES197/E: ENGLISH HOPPER INSTALLATION EXTERNAL HOPPER - NARROW TAG INSERT INTERNAL HOPPER - WIDE TAG INSERT a. Install External Hopper (see photo). b. Install proper External and Internal hopper inserts to match marker plate height. (see photo). c. Place appropriate plate weight on top of stack. Close machine cover by unlatching lock mechanism located in the left rear of inside cover. -
Page 12: Production - Hopper
Please refer to the section on “Error Messages and Problem Solving” for a description of the errors that can arise. CONSOLE The console of the PES197 and PES197/E has two units: a front display and a membrane keypad. The following list describes the structure of the front control panel: •... -
Page 13: Keyboard Description
PES197 and PES197/E: ENGLISH KEYBOARD DESCRIPTION The following list describes the 6 function keys and their actions: SETUP: This key is used to access the programming menu or other internal functions of the machine. A Password enables this command. CARD TEST: This key enables the production of test plates with a pre-determined format. -
Page 14: Displaying The Counters Of The Produced Plates
PES197 and PES197/E: ENGLISH EMB. MODE: This key selects the operational mode of the embossing cycle. It is used for tests and there are 8 choices based on the combinations of the following 3 modes: CONTINUOUS: Repeats the last processed plate continuously WITHOUT PLATE: Runs the operating cycle without controlling for the presence of a plate PAUSE: Executes each operation in response to the user input. -
Page 15: Error Messages And Problem Solving
PES197 and PES197/E: ENGLISH ERROR MESSAGES AND PROBLEM SOLVING In case of breakdown or operator error, the machine will show what caused the machine cycle interruption on the display and on the monitor. The error signal is shown by an error code, followed by the corresponding message (refer to Error List). Please consult the “Problem Solving”... -
Page 16: Problem Solving
PES197 and PES197/E: ENGLISH The table below can be consulted as soon as the error code has been identified. Having corrected the error condition, press PAUSE/START or FEED in order to restore the working state of the Embosser. PROBLEM SOLVING... -
Page 17: General Maintenance
PES197 and PES197/E: ENGLISH ERROR CAUSE SOLUTION E-55 “Top translation table” setup not Reload the setup parameters configured E-61 Communication error Control the setup configuration of the embosser or Host message strings E-62 Communication error Control the setup configuration of the... -
Page 18: Oiling The Trolley Track And Clamp Guide
Every 6 months, Lubricate Every year Lubricant or as needed X & Y Guides 3-in-One Oil ® Contact PANDUIT Tool Service for the maintenance items listed below: High temperature red Carriage Bearing lithium grease High temperature red Dies lithium grease... -
Page 19: Contact Information • For Technical Support
