www.ti.com
3.2
Connector Index
The C5545 BoosterPack board has several connectors that provide access to various interfaces on the
board.
Connector
J1,J9
J5, J6
J3
J11
J7, J8
J12
SPRUI90 – September 2016
Submit Documentation Feedback
Table 4. C5545 BoosterPack Board Connectors
Part Number
10118194-0001LF
SJ-43514
DM3AT-SF-PEJM5
10051922-1410ELF
SSQ-110-23-L-D
20021121-00010C4LF
Figure 28. Connectors on C5545 BoosterPack - Top
Copyright © 2016, Texas Instruments Incorporated
C5545 BoosterPack Board Physical Specifications
Pins
Function
9
Micro USB connector
4
Audio jack
14
Micro SD connector
14
OLED display header
20
LaunchPad headers
10
CC2650 JTAG header
TMS320C5545 BoosterPack Hardware
31
