2.14 I2C Address Mapping

The address mapping for I2C interface on C5545 BoosterPack board is provided in
Master
C5545 DSP
LaunchPad

2.15 GPIO Mapping

The GPIO mapping for C5545 BoosterPack Board is provided in
GPIO Name
CC2650_PWRMGT1
CC2650_PWRMGT2
DSP_SDCD
SWITCH2
SWITCH3
SWITCH4
LED1
LED2
LED3
3

C5545 BoosterPack Board Physical Specifications

This section describes the physical layout of the C5545 BoosterPack board and its connectors, switches
and test points. It contains:
• Board Layout
• Connector Index
• Push Buttons
• Test Points
• LEDs
28
TMS320C5545 BoosterPack Hardware
Table 2. I2C Address Mapping
Slave Device
LaunchPad
INA Devices
OLED Display
Audio CODEC
C5545 DSP
Table 3. GPIO Mapping
C5545 DSP Pin
GP[10] POWER MANAGEMENT
GP[11] POWER MANAGEMENT
GP[29]
GP[12]
GP[13]
GP[14]
GP[16]
GP[17]
GP[28]
Copyright © 2016, Texas Instruments Incorporated
Address
User Programmable
0x40,0x41,0x44,0x48
0x3C
0x18
User Programmable
Table 3.
Purpose Pull Up (PU)/Pull Down (PD0
SD CARD DETECT
KEYPAD
KEYPAD
KEYPAD
LED
LED
LED
Submit Documentation Feedback
www.ti.com
Table 2.
Internal/External
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
INTERNAL PD
