CALL
The CALL LED (red) indicates status of the audio information
transmitted to the central station.
Table 3: CALL LED status
Duty cycle
Rate (±10%)
100%
0%
10%
1 s
50%
1 s
RSSI
The RSSI LED (green) indicates the field strength or signal strength
found by the GSM module. The number of flashes indicates the
level.
Table 4: RSSI LED status
Flashes
Description
Off
No field strength (no network detected).
1 to 4
Field strength indication from poor (1) to excellent (4).
NET
The NET LED (green) indicates the status of the network. The
meaning of the number of flashes is indicated in the table below.
Table 5: NET LED status
Flashes
Description
Off
Not registered
On
Registered to home network
1
Registered to roaming network
2
Searching network
3
Denied
4
Unknown
PSUE
The PSUE LED (red) indicates the status of the power supply.
Table 6: PSUE LED status
State
Description
Off
Power supply okay
On
No battery connected, or other power supply problem
GPRS
For future use.
SIME
The SIME LED (red) indicates the status of the SIM card. The
meaning of the number of flashes is indicated in the table below.
Table 7: SIME LED status
Flashes
Description
Off
Ready
1
PIN error
2
PUK error
3
PIN 2 error
4 of 30
Description
Connected
Offline
Connecting
Ringing present
Flashes
Description
4
PUK 2 error
5
SIM blocked from network
On
SIM not present

Specifications

Power supply:
Via ribbon cable from control panel
Via CON1, from backup battery
Current consumption (at 13.8 V
MI bus
GSM online via battery leads
GSM online max. via battery leads
Dimensions
Battery type and max. capacity
Weight
Temperature
Relative humidity

Regulatory information

Certification
European Union
1999/5/EC (R&TTE directive): Hereby, GE Security
directives
declares that this device is in compliance with the
essential requirements and other relevant provisions
of Directive 1999/5/EC.
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European
manufacturers must designate an authorized
representative in the Community. Our authorized
manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
This product was tested and certified to EN 50136-1
and EN 50136-2 for Alarm transmission system
performance ATS 2 (D2, M2, T3, S1, I0).

Contact information

For contact information see our Web site: www.gesecurity.eu.
DA: Installations vejledning
Indledning
ATS7310 giver mulighed for alarm transmission via GSM på
følgende ATS centraler:
ATS Advisor Master: ATS2000, 3000 og 4000 serie
ATS Advisor Advanced (ATS-Alarm): ATS1000A serie
10 to 15 V
10 to 15 V
±5%):
20 mA
20 mA
0.3 A
104 x 50 mm
Lead acid rechargeable
18 Ah 12 V nom. (BS131)
44 g
0 to 50°C
Max 95% noncondensing
P/N 146376999-3 • REV 3.0 • ISS 29OCT09
