Error Codes; Technical Data; Right Of Complaint - RUSTA DALLAS Manual

ENG

ERROR CODES

8.8.8. Display will flash for 1–2 seconds when first plugged into power outlet.
This is normal, not an indication of a problem.
ErP Error Power will occur when barbecue is plugged into power outlet
and the temperature control knob is not in "OFF" position.
. . . Flashing Dots indicate that the igniter is "ON". The igniter will stay on
for 5 minutes and then go off.
ErH High Temp Limit indicates that the temperature in the cooking
chamber has exceeded 300˚C.
1.0.5. Flashing Temperature indicates temperature is below 45˚C on "LOW"
setting or temperature is below 65˚C on all cooking temperatures.
Err Err Thermocouple may be unhooked or damaged.

TECHNICAL DATA

Voltage
220-240V~50 Hz
Power 260W
Weight 49 kg
Dimensions L110 x W90 x H52 cm
NOTE! See assembly instruction on page 38–47.

RIGHT OF COMPLAINT

By law the product must be returned to the place of purchase along with the original
receipt in the event of a complaint. The user is liable for any damage to the product that
is caused by not using the product for its intended purpose or by not following this user
manual correctly. The right of complaint will not apply in these instances.
INFORMATION ABOUT HAZARDOUS WASTE
Used products should be handled separately
from household waste. They should be taken
for recycling in accordance with local rules for
waste management.
8
• The 180˚F to 300˚F temperature settings are for slow cooking.
• Adjust the control knob to a desired temperature. The selected temperature will be in
the bottom left hand corner of the digital display.
• Adjusting the smoke mode to a higher setting will cause more fl uctuation in the
temperature of the cooking chamber.
• Smoke Mode can be adjusted from P0 to P7. P0 provides less smoke into the cooking chamber and can
be adjusted up to P7 for maximum smoke.
ERROR CODES:
• "8.8.8." – Display will fl ash for 1-2 seconds when fi rst plugged into power outlet.
This is normal, not an indication of a problem.
• "ErP" – Error Power will occur when grill is plugged into power outlet and the
temperature control knob is not in "OFF" position.
• ". . ." – Flashing Dots indicate that the igniter is "ON". The igniter will stay on for
5 minutes and then go off.
• "ErH" – High Temp Limit indicates that the temperature in the cooking chamber
has exceeded 565˚F.
• "1.0.5." – Flashing Temperature indicates temperature is below 110˚F on
"SMOKE" setting or temperature is below 150˚F on all cooking temperatures.
• "Err" – Thermocouple may be unhooked or damaged.
275
250 300 O
K
E
325
225
350
180
375
Smoke
˚F
Off High
8.8.8.
˚F
1.0.5.
P3
COOK
225
˚F
1.0.5.
P3
COOK
225
8
