- Page 1 HD140 PNP Manual User manual and video please visit：WWW.LDARC.COM PRODUCT>>MULTROTOR>>ET SERIES>>HD140 PNP HD140 manual Caddx.US Turtle V2 191120...
- Page 2 Configuration Description Wheelbase：140mm Drone weight： 159.8g(HD )/151.6g(FPV) weight not include receiver and battery Package size : 214*184*90mm Package weight：565.8g(HD)/550.1g(FPV) Bumper：2.8 inch all surround Plate：PCB 2mm，Carbon plate 3mm 。 Camera angle：15-50 Mounting size：Flytower 20*20mm，Motor Φ9mm M2*9，Camera 14mm/19mm KK Tower new name : KKT16 mounting size 16*16mm KKT20 mounting size 20*20mm KKT30 mounting size 30.5*30.5mm...
- Page 3 Pin definition AUDIO BATTERY+ CURRENT BATTERY+ SIGNAL BATTERY+ VIDEO AUDIO PWM4 PWM3 PWM2 PWM1 BATTERY+ BETAFLIGHT 5V(BUZZER+) LED STRIP PPM+RX2-INV BUZZER- TX2-INV BATTERY+ RX2-INV VIDEO Supply voltage is 5V Supply voltage is 3.3V S.BUS and PPM receiver connection DSM2 and DSMX receiver connection PPM or invert RX2 signal input NOT invert RX2 signal input SBUS/PPM...
- Page 4 VTX(IRC-Tramp) Band A 5865 5845 5825 5805 5785 5765 5745 5725 Band B 5733 5752 5771 5790 5809 5828 5847 5866 Band E 5705 5685 5665 5645 5885 5905 5925 5945 Band F 5740 5760 5780 5800 5820 5840 5860 5880 Band H 5658...
- Page 5 Recording 1.HD Recording opration : Short press for 1S , start recording , red LED flashes ; short press for 1s , recording end , red LED is always on . 2.FPV Recording opration：It canable to mounting the most of sport camera , and 3 shift angle adjusted FIREFLY 2 HERO4 SESSION...
- Page 6 Receiver bind AC900(S-FHSS+D16) bind,transmitter(FRSKY X9D/Futaba T18SZ) Bind:Check receiver mode before bind,the first blink after power on indicate the setting, is S-FHSS, is D16 FUTABA S-FHSS BIND:Turn on the TX then power on AC900 while pressing the key, green LED fast blink meaning already in bind mode, user can release the key.
- Page 7 RX2A PRO Bind(S.BUS),transmitter(FLYSKY FS-i6) BIND:Power on the receiver while pressing the key,green LED fast blink meaning already in bind mode, user can release the key,then set your TX into bind mode.Green LED turn off and red LED solid mean bind finished, exit TX from bind mode,receiver’...
-
Page 8: Firmware Update
Firmware Update BETAFLIGHT firmware allready flash before leave the factory,user just need connect PC to adjust the parameter 1.Open betaflight configuration ,then click ,select FW version MATEKF411 4.0.2- MATEKF411 -05-05-2019 20:33(stable) 2.Click ,then click to download FW to FC, click after FW Connect updating finish into setting menu... - Page 9 5.Select ESC protocol is DSHOT600,then follow the steps to set up 6.PID setting...
- Page 10 7.Mode setting...
- Page 11 8.OSD setting 9.LED setting -10-...
- Page 12 Product and Factory Code Name Factory code HD140 NO RX PNP.HD140.NO RX HD140-FPV NO RX PNP.HD140-FPV.NO RX HD140 AC2000 PNP.HD140.AC2000 HD140-FPV AC2000 PNP.HD140-FPV.AC2000 HD140 KIT KIT.HD140 14.8V 430mAh 80C BAT.14.8V 430MAH 80C RunCam Nano2 CAM.Nano2（700TVL 1/3’ CMOS NTSC） 2.8 inch all surround bumper 2.8 INCH PROTECTOR BUMPER(ALL) HD140 body frame PART.HD140 BODY FRAME...
