- Page 1 ET85D PNP Manual User manual and video please visit：WWW.LDARC.COM PRODUCT>>Multirotor>>ET Series>>ET85D PNP ET85D Manual 200430...
- Page 2 Motor Φ9mm M2*7，Camera 19mm/20mm Configuration FC+ESC：F411E12A DJI Digital FPV System Motor : XT1105-4250KV Prop : 2045-4blade Recommend Battery : LDARC 14.8V 430mAh XT30(Need buy another) Note : Drone weight not include receiver and battery Package list ET85D(DJI Digital FPV System)*1 ET85D*1 2045-4blade*10pairs...
- Page 3 F411E12A parameters Invert RX2 <1> STM32F411 MCU,Operation at 100Mhz,firmware target MATEKF411. Invert TX2 <2> MPU-6000 six-axis SPI sensor. <3> Low power version AT7456E,support Betaflight OSD. <4> BEC use MP9943 High-Efficiency Synchronous mode DC-DC, Buzzer+ support 5V@1.5A output. Buzzer- <5> TX1 and RX1 pads,can support IRC-Tramp or Camera control. <6>...
- Page 4 ET85D（DJI Digital FPV System） 7.4-17.6V DJI HDL DJI Digital FPV system install 1.Open canopy,connect DJI Digital 2.Install DJI Digital FPV Sytem FPV Sytem 3.Stick EVA 4.Use screw install canopy...
- Page 5 ET85D（Caddx VISTA） Caddx VISTA SBUS 7.4-26.4V Caddx Vista install 1.Remove the FC ,then weld the Vista and 2.Use ST1.4*4 screw install FC and Vista rack FC together 3.Use ST1.4*10 screw install Vista 4.Use M2*4 screw install camera, then install canopy...
- Page 6 Receiver bind AC900(S-FHSS+D16) bind,transmitter(FRSKY X9D/Futaba T18SZ) Bind:Check receiver mode before bind,the first blink after power on indicate the setting, is S-FHSS, is D16 FUTABA S-FHSS BIND:Turn on the TX then power on AC900 while pressing the key, green LED fast blink meaning already in bind mode, user can release the key.
- Page 7 RX2A PRO Bind(S.BUS),transmitter(FLYSKY FS-i6) BIND:Power on the receiver while pressing the key,green LED fast blink meaning already in bind mode, user can release the key,then set your TX into bind mode.Green LED turn off and red LED solid mean bind finished, exit TX from bind mode,receiver’...
-
Page 8: Firmware Update
Firmware Update BETAFLIGHT firmware allready flash before leave the factory,user just need connect PC to adjust the parameter 1.Open betaflight configuration ,then click ,select FW version MATEKF411 3.5.6- MATEKF411 -02-16-2019 13:21(stable) 2.Click ,then click to download FW to FC, click after FW Connect updating finish into setting menu... - Page 9 6.PID Setting...
- Page 10 7.Mode setting -10-...
- Page 11 Product and Factory Code Name Factory code ET85D(Include DJI Digital FPV System) PNP.ET85D ET85D PNP.ET85D ET85D KIT KIT.E85D 14.8V 430mAh 80C BAT.14.8V 430MAH 80C ET85 Carbon plate PART.ET85 CARBON PL ATE 2045-4blade PROP.2045.4.WHITE XT1105-4250KV MOTOR.XT1105-4250KV F411E12A FC.F411E12A ET85D main frame PART.ET85D MAIN FRAME(2PCS) After Sale Service 1.Provide free reparation service when find the product defect after purchase.
