THUNDER 600X
说明书和视频教程请访问：WWW.LDARC.COM
分类 》 FPV飞翼 》 THUNDER 600X
User manual and video please visit：WWW.LDARC.COM
Departments 》 FPV FLY WING 》 THUNDER 600X
副翼和升降/Aileron and Elevator
155mm
30
30
重心/Center of gravity
-1-
描述/Specification
配置/Configuration
翼展/Wingspan:656mm
电机/Motor:A2205-2500KV
长度/Length:357mm
电调/ESC:35A BLheli
材质/Material:EPO
UBEC:2-6S 5V 3A
电池仓尺寸/Battery position size:
舵机/Servo:12g EMAX ES08MA Ⅱ
91*35*21mm
图传/VTX:5.8G 400mW Mini 40CH
摄像头/Camera:RunCam Swift Mini
螺旋桨/Prop:5*5E and 6*4E
颜色/Color:橙色或黑色/Orange or Black
PNP
FLY WING
KIT
+
PNP PARTS
PNP+FPV
FLY WING
KIT
+
+
PNP PARTS
FLY WING PNP PARTS
A2205-2500KV*1PC
ES08MA Ⅱ Servo*2PCS
FLY WING FPV PARTS
RunCam Swift Mini*1PC
Antenna*1PC（Height size:36.5mm）
400mW VTX*1PC(90
FLY WING
FPV PARTS
UBEC*1PC
A-35A ESC*1PC
。
)
*1PC
-2-
Cooling fin*1PC
*1PC
