- Page 1 90/130GTI Manual User manual and video please visit：WWW.LDARC.COM PRODUCT>>MULTROTOR>>GT SERIES>>90/130GTI PNP 90/130GTI manual Video manual 190805...
- Page 2 3-4S 600-800mAh Battery 3S(Recommend voltage) 4S(Recommend voltage) 3S(Recommend voltage) 4S(Recommend voltage) Voltage 139.1g 128.4g 83.7g 74.1g Weight 1080P/60fps 16:9 64G 1080P/60fps 16:9 64G Video The weight not include receiver,battery,prop and bumper;130GTI recommend battery LDARC 14.8V 650mAh 50C 90GTI(HD) 90GTI(FPV) 130GTI(HD) 130GTI(FPV)
- Page 3 Package list 90GTI(HD) 90GTI(HD)*1 Racing booth*1 Set Bumper(half surround)*1 Set 11.4V 530mAh 80C*1 Canopy*1 Sticker*1 Receiver manual*1 90GTI(FPV) 90GTI(FPV)*1 Racing booth*1 Set Bumper(all surround)*1 Set 11.4V 530mAh 80C*1 Canopy*1 Sticker*1 Receiver manual*1 130GTI(HD) 130GTI(HD)*1 TPU *2 Canopy*1 3050*10 Pairs Receiver manual*1 130GTI(FPV) 130GTI(FPV)*1 TPU*2...
- Page 4 Pin definition AUDIO BATTERY+ CURRENT BATTERY+ SIGNAL BATTERY+ VIDEO AUDIO PWM4 PWM3 PWM2 PWM1 BATTERY+ BETAFLIGHT 5V(BUZZER+) LED STRIP BATTERY+ PPM+RX2-INV BUZZER- VIDEO Only KKT-F411(20x20)-90214 version TX2-INV BATTERY+ RX2-INV VIDEO Supply voltage is 5V Supply voltage is 3.3V S.BUS and PPM receiver connection DSM2 and DSMX receiver connection PPM or invert RX2 signal input NOT invert RX2 signal input...
- Page 5 Band A 5865 5845 5825 5805 5785 5765 5745 5725 Band B 5733 5752 5771 5790 5809 5828 5847 5866 Band E 5705 5685 5665 5645 5885 5905 5925 5945 Band F 5740 5760 5780 5800 5820 5840 5860 5880 Band H 5658 5695...
- Page 6 Receiver bind AC900(S-FHSS+D16) bind,transmitter(FRSKY X9D/Futaba T18SZ) Bind:Check receiver mode before bind,the first blink after power on indicate the setting, is S-FHSS, is D16 FUTABA S-FHSS BIND:Turn on the TX then power on AC900 while pressing the key, green LED fast blink meaning already in bind mode, user can release the key.
- Page 7 RX2A PRO Bind(S.BUS),transmitter(FLYSKY FS-i6) BIND:Power on the receiver while pressing the key,green LED fast blink meaning already in bind mode, user can release the key,then set your TX into bind mode.Green LED turn off and red LED solid mean bind finished, exit TX from bind mode,receiver’...
-
Page 8: Firmware Update
Firmware Update BETAFLIGHT firmware allready flash before leave the factory,user just need connect PC to adjust the parameter 1.Open betaflight configuration ,then click ,select FW version MATEKF411 3.5.3- MATEKF411 -15-11-2018 13:35(stable) 2.Click ,then click to download FW to FC, click after FW Connect updating finish into setting menu... - Page 9 (10) (11) 6.PID set...
- Page 10 7.Mode set 7.LED set...
- Page 11 Product and Factory Code Name Factory code Factory code Name 2035 Prop PROP.2035.4.WHITE 90GTI(HD) NO RX PNP.90GTI(HD).NO RX 2045 Prop PROP.2045.4.WHITE PNP.90GTI(FPV).NO RX 90GTI(FPV) NO RX 3050 Prop PROP.3050.3.WHITE 90GTI(HD) AC2000 PNP.90GTI(HD).AC2000 XT1406-3600KV MOTOR.XT1406-3600KV 90GTI(FPV) AC2000 PNP.90GTI(FPV).AC2000 MOTOR.XT1105-5000KV XT1105-5000KV 130GTI(HD) NO RX PNP.130GTI(HD).NO RX 4in1 ESC 20A ESC.KK TOWER 20A...
