Description Of The Device; Front - SHOWTEC Performer Profile Mini MKII 3200K Manual

Performer Profile Mini MKII 3200K

Description of the device

Features
The Showtec Performer Profile Mini MKII 3200K is a compact theater spotlight fixture with high output.
● Input voltage: 110–240 V AC, 50/60 Hz
● Power consumption: 25 W
● Drive current: 0,5 A
● Light source: 1 x 30 W COB
● Lux @ 1 m: 15000 (19°)
● Color rendering: >90Ra
● Color temperature: 3200K
● Dimmer: Manual, DMX/RDM
● Beam angle: 19° > 36° fixed and zoom
● Connections: Schuko power cable, 3-pin DMX signal connector IN/OUT
● Mounting: Portable/track-mount
● Housing: Die-cast aluminum
● Cooling: Forced convection
● Color: Black
● IP rating: IP20
● Dimensions: 150 x 106 x 225 mm (LxWxH)
● Weight: 1,3 kg
Optional accessories
33082 – Lens Tube Black 19º
33083 – Lens Tube Black 26º
33084 – Lens Tube Black 36º
33085 – Glare Shield for Performer Profile Mini
33086 – Gobo Holder for Performer Profile Mini
33087 – Zoom Lens for Mini Profile 19º > 36º
33088 – Shutter barrel

Front

01) Mounting bracket with inclination screw
02) Safety eye
03) Adjustment screw
04) Shutter (not included)
05) Shutter barrel (not included)
06) 1 x 30 W COB
Ordercode: 33090
7
Fig. 01
