Performer Profile Mini MKII 3200K

Multiple Performers (DMX/RDM Control)

01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Performers and other devices.
04) Link the units as shown in fig. 09. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third and fourth units.
05) Supply electric power: Plug the mains power cords into proper electric power supply sockets,
starting with the first unit. Do not supply power before the whole system is set up and connected
properly.
Multiple Performers DMX/RDM Setup
Ordercode: 33090
Note: Link all cables before connecting electric power
12
Fig. 09
