TP48200A-D17A5-2 Telecom Power
User Manual
Pin
3
7
6
8

3.6 UIM02C

Panel
The user interface module (UIM02C) supports eight dry contact outputs, nine dry contact
inputs (including six universal dry contact inputs, one smoke sensor input, one water sensor
input, and one door status sensor input), and four analog parameter inputs (including one
ambient temperature and humidity input, two ambient temperature inputs, and one battery
temperature input).
Figure 3-8 shows a UIM02C panel.
Figure 3-8 UIM02C panel
Ports
Table 3-8 UIM02C ports
Port Type
Sensor ports
Dry contact input ports
Issue 04 (2019-12-20)
Signal
RX232
TX232
PGND
NA
Silk Screen
TEM-HUM
WATER
TEMP1
TEMP2
GATE
SMOKE
BTEMP
DIN1
Copyright © Huawei Technologies Co., Ltd.
Description
Ambient temperature and humidity sensor
Water sensor
Ambient temperature sensor 1
Ambient temperature sensor 2
Door status sensor
Smoke sensor
Battery temperature sensor
NOTE
3 Components
Description
Receives data over RS232.
Transmits data over RS232.
Connects to the ground.
–
