Port
Power Cord
Serial (Console)
Ethernet (UP1, UP2, or
MGN)
PHONE
LINE
2.3.2 IP DSLAM Slave Console Port Setup
For the initial configuration, users need to use terminal emulator software on a
computer and connect it to a network module through the console port. Users can
connect the RJ-45 end of the console cable to the console port of the network module.
On the other side, users can connect the other end to serial ports of a computer.
$help
Command
------- -----------
alias To alias a command
commit Commit the active configuration to the flash
create Create a new entry of specified type
delete Delete the specified entry
download Download a file on to the Device
exit To exit the CLI shell
get Display info for the search
help Provides help
modify Modify information for specified entry
passwd To modify user password
ping The normal ping command
prompt Change the user prompt
reboot Reboot the device
reset Reset info for the specified entry
traceroute The normal traceroute command
unalias To undefine previously defined alias
verbose Switch ON/OFF the verbose mode
VigorAccess User Installation Guide
Table 2-3. IP DSLAM slave connections
Type, Color
Cord, Black
Wire with lug
terminal
RS232, Grey
RJ-45, Blue
RJ-21,
RJ-21,
Description
Connected to
AC Inlet
DC Inlet
Connect to PC RS232
port for debug
Uplink interface to
connect to Master
subtend interface or to
PC for management
To PSTN
To subscriber copper line
41
Remarks
100-240VAC
-42 ~ 56VDC
--
