Table 2-2. IP DSLAM master DSL LED descriptions
PWR
Green The Power LED is on when Power is applied.
OFF The Power is not applied.
M_ACT
Green Blink when Master is active.
OFF OFF when system is hanged.
M_CR
Green Master critical alarm is present.
OFF No critical alarm is present to system.
M_MJ
Green Master Major Alarm is present.
OFF No major alarm is present to system.
M_MN
Green Master Minor Alarm is present.
OFF No minor alarm is present to system.
Gx
LNK
Green Subtend interface by GE Interface.
Green when Ethernet link is established Blinks during data
transmitting/receiving.
OFF OFF means No Ethernet link established.
1000
Green The speed for Ethernet is 1000Mbps when LNK LED is ON.
OFF The speed for Ethernet is 10/100Mbps when LNK LED is ON.
FDX
Green The Ethernet is in full duplex mode when LNK LED is ON.
OFF The Ethernet is in half duplex mode when LNK LED is ON.
ACT
Green
Blink: DSL board is Active.
OFF
OFF or solid ON when system is inactive.
CR
Red
DSL critical alarm is present.
OFF
No critical alarm is present to system.
MJ
Red
DSL Major Alarm is present.
OFF
No major alarm is present to system.
MN
Yellow
DSL Minor Alarm is present.
OFF
No minor alarm is present to system.
DSLx
Green
The DSL x Port link status is Up.
Blinking The DSL link is training.
OFF
The DSL x Port link status is down.
VigorAccess User Installation Guide
39
