Vecow SPC-3000 User Manual page 12

Storage Device
Audio
Audio Codec
Audio Interface
Ethernet
LAN 1
LAN 2
LAN 3
LAN 4
Power
Power Input
Power Interface
Remote Switch
Others
Watchdog Timer
Smart Management
HW Monitor
Software Support
Microsoft
Linux
Mechanical
Dimensions (WxLxH)
Weight
Mounting
Environment
Operating Temperature
Storage Temperature
Humidity
Relative Humidity
Shock
Vibration
EMC
1 2.5" SSD/ HDD Bracket (Internal)
Realtek ALC892, 5.1 Channel HD Audio
1 Mic-in, 1 Line-out
®
Intel I219LM Gigabit LAN supports iAMT 11.0
®
Intel I210 Gigabit LAN
®
Intel I210 Gigabit LAN
®
Intel I210 Gigabit LAN
9V to 36V, DC-in
3-pin Terminal Block : V+, V-, Frame Ground
2-pin Terminal Block : On, Off
Reset : 1 to 255 sec./min. per step
Wake on LAN, PXE supported
Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Windows 10, Windows 8.1, Windows 7
Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
150mm x 106mm x 68mm (5.9" x 4.2" x 2.7")
1.3 kg (2.87 lb)
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
-40°C to 70°C (-40°F to 158°F)
-40°C to 85°C (-40°F to 185°F)
5% to 95% Humidity, non-condensing
95% at 70°C
• IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
• IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
CE, FCC, EN 50155, EN 50121-3-2
GENERAL INTRODUCTION 5
