Vecow SPC-3000 User Manual page 10

Graphics
Graphics Processor
Interface
Storage
SATA
mSATA
Storage Device
Audio
Audio Codec
Audio Interface
Ethernet
LAN 1
LAN 2
Power
Power Input
Power Interface
Remote Switch
Others
Watchdog Timer
Smart Management
HW Monitor
Software Support
Microsoft
Linux
Mechanical
Dimensions (WxLxH)
Weight
Mounting
Environment
Operating Temperature
Storage Temperature
Humidity
®
Intel HD Graphics 520
• DVI-D : Up to 1920 x 1200
• DisplayPort : Up to 4096 x 2304
2 SATA III (6Gbps)
1 SATA III (Mini PCIe Type, 6Gbps)
1 2.5" SSD/ HDD Bracket (Internal)
Realtek ALC892, 5.1 Channel HD Audio
1 Mic-in, 1 Line-out
®
Intel I219 Gigabit LAN supports iAMT 11.0
®
Intel I210 Gigabit LAN
9V to 36V, DC-in
3-pin Terminal Block : V+, V-, Frame Ground
2-pin Terminal Block : On, Off
Reset : 1 to 255 sec./min. per step
Wake on LAN, PXE supported
Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Windows 10, Windows 8.1, Windows 7
Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
150mm x 106mm x 44mm (5.9" x 4.2" x 1.7")
0.9 kg (1.98 lb)
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 1U Rackmount (Optional)
-40°C to 70°C (-40°F to 158°F)
-40°C to 85°C (-40°F to 185°F)
5% to 95% Humidity, non-condensing
GENERAL INTRODUCTION 3
