INIM PREVIDIA COMPACT Installation Manual page 9

Installation manual
Note:
The control panels described in this manual have been designed and developed to the highest standards
of quality, reliability and performance.
The components selected for this product will operate properly within their specifications when the
environmental conditions outside the product enclosure comply with Class 3k5 (EN 60721-3-3).
EN54:
The gas detection function is not provided for in the aforesaid standard and therefore cannot be
considered EN54-2 compliant.
Specification
Supply voltage
Maximum current draw 230V
AC Mains input terminals
Nominal output voltage
Maximum output current
Main board current draw
LED indicators board current draw
Maximum battery-charge current
Battery specifications
Maximum internal resistance of the batteries (R
Output voltage
Battery shutdown tension
Internal fuse of switching power supply module
Maximum output current ripple
Operating temperature
Isolation class
Enclosure protection class (EN 60529)
Dimensions
Weight (without batteries)
When you remove the four screws and metal-frontplate, you will find:
General description
I
max. a
I
max. b
(if present)
i max
Previdia Compact Models
PREVIDIA-CxxxS
(in small cabinet)
230V~ (-15% / +10%) 50/60Hz
0.5 A
AC Input
230V ~ 50/60 Hz
L N
1.5 A
1.5 A
1.5 A
stand-by
without supply voltage
test LEDs
stand-by
test LEDs
0.6 A
2 x 12 V, 7 Ah
with UL94-V2 flame class cabinet or higher
)
2.7 Ohm
420 mV
322 x 324 x 86 mm
3.3 Kg
PREVIDIA-CxxxL
(in large cabinet)
1.1 A
AC Input
230V ~ 50/60 Hz
N L
27.6 V
4 A
4 A
4 A
150mA
130mA
170mA
5mA
115mA
1.2 A
2 x 12 V, 17 Ah
1 Ohm
from 19 to 27.6V
19V
T 3.15A 250V
260 mV
from -5°C to 40°C
I
IP30
497 x 380 x 97 mm
6.1 Kg
9
