Installation manual
-
3.4

Connecting the "I/O" terminals

Each of the 4 IN/OUT channels of the control panel (terminals 19-20, 21-22, 23-24, 25-26) can be configured as:
• supervised output
• input
Cables:
2 wire shielded cable
Proper section (minimum 0.5mm², maximum 2.5 mm²)
Compliant with local laws and regulations in force
Installation
C
C
A
D
B
A
A
-
+
B
-
+
Previdia Compact in
large cabinet
C
+
D
Previdia Compact in
small cabinet
-
A
+
C
