Previdia Compact REP Repeater

For installations requiring a system control point other than the point where the Previdia Compact control panel is
installed, there are two repeater panel models, that is, devices that allow you to remotely view the information available
on the user interface of the control panel.
The models are:
• PREVIDIA-C-REP, standard repeater
• PREVIDIA-C-REPE, standard repeater with extinction channel LEDs
Touchscreen
[A]
display
[B]
Status LED
LED and function
[C]
button
LED and multiple-
[D]
alarm button
[E]
Access-key slot
[F]
Buzzer
MicroSD card
[G]
holder
K
B
A
D
16
Technical specifications
stand-by
maximum
2G: 850/900, 1800/1900 MHz
3G: 800/850/900, 1900/2100 MHz
remote GSM-UMTS cable 2m, SMA-Male
connector (50Ohm impedance) and magnetic
[H] Ethernet port
[I]
Mini USB port
[J]
Terminal board
[K] Backlocking grips
[L]
Cable entry
Mounting screw
[M]
locations
[H] Ethernet port
K
C
F
19-30 V
40mA
140mA
2W, 1W
from -5°C to +40°C
base
K
M
L
M
M
I
H
E
