Eaton Power XL SmartWire-DT DX-NET-SWD Series Manual page 94

5 Appendix
5.1 Dimensions
90

Ready
I
A
O
1 2 3 4 5 6 7 8 9 10 11

50 mm (1.97")
81 mm (3.19")
Figure 31: Variable frequency drive DC1 in FS1 with SmartWire-DT connection

Ready
I
A
O
1 2 3 4 5 6 7 8 9 10 11

75 mm (2.95")
107 mm (4.21")
Figure 32: Variable frequency drive DC1 in FS2 with SmartWire-DT connection
DX-NET-SWD... 08/14 MN04012009Z-EN www.eaton.com
EMC
VAR
4 mm (0.16")
144 mm (5.67")
156.8 mm (6.17")
EMC
VAR
5 mm (0.2")
172 mm (6.77")
184.8 mm (7.28")
⌀ 6 m m
(⌀ 0 .2 4 ")
⌀ 1 2 m m
(⌀ 0 .4 7 ")
⌀ 6 m m
(⌀ 0 .2 4 ")
⌀ 1 2 m m
(⌀ 0 .4 7 ")
