4.4 Cyclic data

4.4.1 Introduction

Profile
No. Name
1 DX-NET-SWD 8 bit
2 DX-NET-SWD PD 2 x 16-Bit
VFD = DA1, DC1 variable frequency drive or DE1 variable speed starter
The amount of cyclical input/output data (process data) for the variable
frequency drive/variable speed starter can be adjusted as necessary for the
application at hand by using the various profiles. These profiles can be
selected in the hardware/PLC configuration program (in the SWD-Assist
program, for example).
Two cyclic profiles can be selected:
• Profile 1:
Control and status data will be processed as per the I/O link profile.
• Profile 2:
This group supplements the variable frequency drive profile with the
PROFIdrive profile as the PNO has defined for the cyclic data-exchange
with a drive. Control and status data will be processed according to the
PROFIdrive profile.
Profile 2 is set in the default settings.
Table 6: Profiles
Input bytes (status)
0 1 2 3
Smart FU
Wire-
DT
Smart FU FU FU
Wire-
DT
￫
For information on the subject of the "cyclic data transfer",
consult manual MN05013002Z-EN, "SmartWire-DT Gateways."
DX-NET-SWD... 08/14 MN04012009Z-EN www.eaton.com
Output bytes (control)
4 Σ 0 1
1 + 1 Smart FU
Wire-
DT
FU 1 + 4 Smart FU
Wire-
DT
