This manual contains specific information designed to enable you to connect
a DX-NET-SWD1 or DX-NET-SWD3 SmartWire-DT interface module to a
PowerXL variable frequency drive and to use the relevant parameters to
configure the module according to your specific needs.
The following significant amendments have been introduced since previous
issues:
Publication Page Subject
date
08/14 completely revised,
DX-NET-SWD1 added
06/13 Initial issue
This manual, MN04012009Z-EN, is intended for engineers, electricians, and
automation technicians. Electrical engineering and physics-related
knowledge and skills will be required in order to be able to commission the
corresponding devices. In addition, readers must be familiar with how to use
the SmartWire-DT system.
Further information can be found in the following manuals:
On the topic "Variable frequency drive/Variable speed starter"
• DC1 – MN04020003Z-EN
• DA1 – MN04020005Z-EN
• DE1 – MN040011EN
On "SmartWire-DT":
• "SmartWire-DT The system" – MN05006002Z-EN
• "SmartWire-DT module" – MN05006001Z-EN
• "SmartWire-DT Gateways" – MN05013002Z-DE
￫
The above mentioned manuals and further information can be
found in the internet:
www.eaton.eu/powerxl
[1] Profile Drive Technology, PROFIdrive Technical Specification for
PROFIBUS and PROFINET, Version 4.1, May 2006; Order No: 3.172
