4 Commissioning
4.6 SmartWire-DT diagnostics

4.6.2 Advanced SmartWire-DT diagnostics

4.6.2.1 Advanced SmartWire-DT diagnostics via PROFIBUS
86
When there is a collective diagnostic (input byte 0, bit 4 (DIAG)), the variable
frequency drive/variable speed starter will provide advanced diagnostic
messages.
The following messages are generated by the variable frequency drive/
variable speed starter.
Table 18: Diagnostic alarms of the DC1 variable frequency drive
Value Meaning
[hex]
14 Internal communication
problem in the variable
frequency drive/variable
speed starter
15 no unambiguous position
of the 1-0-A switch for
more than 4 seconds
19 There is a warning at
hand for the variable
frequency drive/variable
speed starter.
1A There is a fault at hand on
the variable frequency
drive/variable speed
starter.
Diagnostic alarm 15
If the 1-0-A switch does not assume a clear position for longer than
4 seconds, the variable frequency drive/variable speed starter will be
switched off and generate the following error messages:
• DIAG,
• ERR,
• Diagnostic alarm 15
In addition, the SmartWire-DT diagnostic LED on the DX-NET-
SWD...SmartWire-DT connection will flash green (frequency: 3 Hz).
￫
For information on the subject of advanced diagnostics, consult
manual MN05013002Z-EN, "SmartWire-DT Gateways".
For basic information on diagnostics via PROFIBUS-DP masters,
consult manual MN05002002Z-EN, "XI/OC Signal Modules".
The manual also contains explanations regarding the access of
the diagnostic data of a PROFIBUS-DP slave module.
DX-NET-SWD... 08/14 MN04012009Z-EN www.eaton.com
Remedy
• If the error continues, switch
the supply voltage off/on
• Check EMC
• Replace the variable
frequency drive/variable
speed starter
Move the 1-0-A switch to one of
the three defined positions.
Read warning PNU 860.0 and fix
the cause
• Read fault PNU 944 to
PNU 952
• Fix the fault and
acknowledge the fault
message
hex
(￫ Table 18).
hex
Notes
Input byte 0, bit array 2..3 A1, A2 is
used to signal a value of 00 .
hex
For more information, see below.
Corresponds to the WARN bit in the
corresponding input byte
Corresponds to the ERR bit in the
corresponding input byte.
