Command access MLRK1 Insert Instructions page 4

Pull gently on the Magnet Bracket to ensure the Rod is fully seated in the Cut Out and use the 1/16"
4
allen wrench to tighten the First Set Screw. Next use the allen wrench to adjust the Second Set Screw
until Magnet Bracket is level.
First Set Screw
5
Rotate the Motor Link until the holes of the Motor Mount align with the existing Dogging Holes, then
install the two phillips head screws provided.
Motor Mount / Dogging Holes
6
Once the Screws are installed, plug the MM4T Socket Lead into the MM4T module.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Magnet Bracket
Motor Link
Screws
Second Set Screw
MM4T Socket Lead
4
Level
# 2 0 0 9 2 _ H
