Command access MLRK1 Insert Instructions page 3

1
Slide Filler Plate off the bar.
2
If the Dogging Assembly is installed, remove the two screws and discard it. If there is Black Foam
sticking out from underneath the Back Activating Bracket, trim and remove.
Dogging Assembly Screws
3
Install the kit onto the Rod located at the bottom of the Activating Bracket, using the Magnet
Bracket's Cut Out.
Activating Bracket
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Rod
Back Activating Bracket
Rod
3
Filler Plate
Black Foam
Magnet Bracket Cut Out
# 2 0 0 9 2 _ H
