Enclosure Dimensions - Altronix HubSat4WPV Installation Manual

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may
be of sufficient magnitude to constitute an electric shock .
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance .
6"
152.4mm
13"
14"
330mm
355.6mm
4.21"
107mm
Altronix is not responsible for any typographical errors .
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A .
IIHubSat4WPV
- 12 -
CAUTION: To reduce the risk of electric shock do not open
enclosure . There are no user serviceable parts inside .
Refer servicing to qualified service personnel .
Enclosure Dimensions (H x W x D approximate):
12" x 8" x 6" (304 .8mm x 203 .2mm x 152 .4mm)
8"
203.2mm
4.05"
103mm
MOUNTING PANEL
GALVANIZED
12"
305mm
H30R
6.7"
170mm
250mm
CARBON STEEL SHEET
9.84"
0.08"
2mm
MEMBER
HubSat4WPV
